How to Program
16-71 Relay Output [bin]
Range:
0 [0 - 511 ]
*
6 6
6.8.2 16-8* Serial communication bus & FC
Port
Parameters for reporting the BUS references and control
words.
16-80 Fieldbus CTW 1
Range:
0 [0 -
*
65535 ]
16-84 Comm. Option Status
Range:
0 [0 - 65535 ] View the extended Serial communication bus
*
16-85 FC Port CTW 1
Range:
0 [0 - 65535 ] View the two-byte control word (CTW) received
*
6-24
VLT Active Filter AAF 00x
Function:
View the settings of all relays.
Function:
View the two-byte control word (CTW) received
from the bus master. Interpretation of the
control word depends on the Serial
communication bus option installed and the
control word profile selected in 8-10 Control
Profile.
For more information, please refer to the
relevant Serial communication bus manual.
Function:
comm. option status word.
For more information, please refer to the
relevant Serial communication bus manual.
Function:
from the bus master. Interpretation of the
control word depends on the Serial
communication bus option installed and the
control word profile selected in 8-10 Control
Profile.
MG.90.V2.22 - VLT
6.8.3 16-9* Diagnosis Readouts
16-90 Alarm Word
Range:
0 [0 - 4294967295 ] View the alarm word sent via the serial
*
16-91 Alarm Word 2
Range:
0 [0 - 4294967295 ] View the alarm word sent via the serial
*
16-92 Warning Word
Range:
0 [0 - 4294967295 ] View the warning word sent via the serial
*
16-93 Warning Word 2
Range:
0 [0 - 4294967295 ] View the warning word sent via the serial
*
16-94 Ext. Status Word
Range:
0 [0 - 4294967295 ] Returns the extended warning word sent
*
®
is a registered Danfoss trademark
Function:
communication port in hex code.
Function:
communication port in hex code.
Function:
communication port in hex code.
Function:
communication port in hex code.
Function:
via the serial communication port in hex
code.
