3.1.3 Ordering Form type code

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39
A A F 0 0 x A
Product groups 1-3
Series 4-6
Current rating 7-10
Phases 11
AC Line Voltage 12
enclosure 13-15
RFI filter 16-17
Display (LCP) 19
Coating PCB 20
Line power option 21
Adaptation A 22
Adaptation B 23
Software release 24-27
Software language 28
A options 29-30
B options 31-32
C option configu- 33-37
ration
D options 38-39
VLT Active Filter AAF 00x
T 4 E H x G
Possible choice
AAF
005
A190: 190Amp
A250: 250Amp
T: Three Phases
4: 380–480V AC
E21: IP21/Nema Type1
ESH: IP54 hybrid
H2: RFI filter, Class A2
(standard)
H4: RFI filter, Class A1 (optional)
G: Graphical Local Control
Panel (LCP)
C: Coated PCB
X: No AC line option
3: Line power disconnect and
fuse
7: Fuse
Reserved
Reserved
Reserved
Reserved
AX: No A option
BX: No B option
CFxxx: CO option occupied
with active filter control card
DX: No Options
®
MG.90.V2.22 - VLT is a registered Danfoss trademark
C x x S x x x x A
Product groups 1-3
Series 4-6
Current rating 7-10
Phases 11
AC Line Voltage 12
enclosure 13-15
RFI filter 16-17
Display (LCP) 19
Coating PCB 20
Line power option 21
Adaptation A 22
Adaptation B 23
Software release 24-27
Software language 28
A options 29-30
B options 31-32
C option configu- 33-37
ration
D options 38-39
x B x C x x x x D x
Possible choice
AAF
006
A190: 190Amp
A250: 250Amp
A310: 310Amp
A400: 400 Amp
T: Three Phases
4: 380–480V AC
E21: IP21/Nema Type1
E54: IP54/Nema Type 12
E2M: IP21/Nema Type 1 with line
power shield
E5M: IP54/Nema Type 12 with
line power shield
H2: RFI filter, Class A2 (standard)
H4: RFI filter, Class A1 (optional)
G: Graphical Local Control Panel
(LCP)
C: Coated PCB
X: No AC line option
3: Line power disconnect and
fuse
7: Fuse
Reserved
Reserved
Reserved
Reserved
AQ: MCA-122 Modbus TCP
AX: No A option
BX: No B option
CFxxx: CO option occupied with
active filter control card
DO: 24V backup
DX: No Options
