General Specifications
Control card, USB serial communication:
USB standard
USB plug
Generic specifications:
Maximum parallel filters
Filter Efficiency
Typical average switching frequency
Response time
Settling time - reactive current control
Settling time - harmonic current control
Overshoot – reactive current control
Overshoot – Harmonic current control
Connection to PC is carried out via a standard host/device
USB cable. The USB connection is galvanically isolated from
the supply voltage (PELV) and other high-voltage
terminals. The USB connection is not galvanically isolated
from protection ground. Use only isolated laptop/PC as
connection to the USB connector on the unit or an
isolated USB cable/drive.
Protection and Features:
•
Temperature monitoring of the heatsink ensures that the active filter trips if the temperature reaches a predefined
level. An overload temperature cannot be reset until the temperature of the heatsink is below the values stated in
the tables on the following pages.
•
If a line phase is missing, the active filter trips.
•
The active filter has a short circuit protection current rate of 100kA if properly fused
•
Monitoring of the intermediate circuit voltage ensures that the filter trips if the intermediate circuit voltage is too
low or too high.
•
The active filter monitors the line power current as well as internal currents to ensure that current levels do not
reach critical levels. Inf the current exceeds a critical level, the filter trips.
VLT Active Filter AAF 00x
®
MG.90.V2.22 - VLT is a registered Danfoss trademark
1.1 (Full speed)
USB type B "device" plug
4 on same CT set
97%
3.0–4.5 kHz
< 0.5ms
< 20ms
< 15ms
<10%
<10%
