How to Install
4 4
889,1
[35]
Figure 4.10 Space in front of IP21/IP54 enclosure type, frame
size E7.
4-10
VLT Active Filter AAF 00x
849,0
[33]
®
MG.90.V2.22 - VLT is a registered Danfoss trademark
1069
1068.91 mm
[42,08]
Figure 4.11 Space in front of IP21/IP54 enclosure type, frame
size E9.
Wire access
Ensure that proper cable access is present including the
necessary bending allowance.
NOTE!
All cable lugs/shoes must mount within the width of the
terminal bus bar.

4.3.3 Terminal Locations - Frame size D

Consider the following position of the terminals when
designing for cables access.
597
597.00 mm
[23,50]
