Danfoss VLT AAF00x Instruction Manual page 21

How to Install
Frame size
4 4
Version
enclosure protection
Nominal current rate
Shipping Dimensions
Filter Dimensions
4-8
VLT Active Filter AAF 00x
Mechanical dimensions and rated power
IP
NEMA
Height (in
[mm])
Width (in
[mm])
Depth (in
76.5 [1943]
[mm])
Weight (lbs
[kg]):
Height (in
68.5 [1740]
[mm])
Width (in
[mm])
Depth (in
[mm])
Max weight
(lbs [kg])
MG.90.V2.22 - VLT
D13
AAF06
21/54
Type 1/12
190A
29.5 [750]
29 [737]
13.4 [340]
23.6 [600]
15 [380]
646 [293]
®
is a registered Danfoss trademark
E9
AAF06
21/54
Type 1/12
250, 310, 400A
34 [864]
29 [737]
86.7 [2203]
19.7 [500]
78.7 [2000]
23.6 [600]
19.4 [494]
1010 [458]
