How to Program
300-52 Sleep Mode Wake Up Trigger
Range:
Application [Application
dependent dependant]
*
300-53 Sleep Mode Sleep Trigger
Range:
80 % [0 - 90 %]
*
6.10 301-**
301-00 Output Current [A]
Range: Function:
0.00 A [0.00 - 10000.00 A] View the RMS output current of
*
the unit.
301-01 Output Current [%]
Range:
0.0 % [0.0 - 10000.0 %]
*
301-10 THD of Current [%]
Range:
0 % [0 - 200 %]
*
301-11 Estimated THD of Voltage [%]
Range: Function:
0% [0–200%] View the total harmonic distortion of the
*
voltage. This value is estimated because the
active filter does not measure the AC line
voltage.
301-12 Power Factor
Range: Function:
0.00 [0.00 - 2.00 ] View the power factor, after compensation
*
by the active filter.
301-13 Cosphi
Range: Function:
0.00 [-1.00 - View the displacement power factor, after
*
2.00 ] compensation by the active filter. Positive
numbers indicate a leading power factor,
while negative numbers indicate a lagging
power factor.
VLT Active Filter AAF 00x
Function:
Only available when [o] Line
Power Current is selected in
300-51 Sleep Mode Trig Source.
The parameter sets the current
% value of 300-20 CT Primary
Rating at which the filter awakes;
5 equals 5% of 300-20 CT Primary
Rating. If CTs are 1500 and this
parameter is 5, this equals 5% of
1500A = 75A wake-up current.
Function:
Function:
Function:
®
MG.90.V2.22 - VLT is a registered Danfoss trademark
301-14 Leftover Currents
Range: Function:
0.0 A [0.0 - 8000.0 A] View the harmonic currents leftover
*
after prioritized harmonic and cos-phi
compensation by the active filter.
301-20 Mains Current [A]
Range: Function:
0 A [0 - 65000 A] View the total harmonic distortion of the
*
current, after compensation by the active
filter.
301-21 Mains Frequency
Range: Function:
0 Hz [0 - 100 Hz] View the total harmonic distortion of the
*
voltage.
301-22 Fund. Mains Current [A]
Range: Function:
0 A [0 - 65000 A] View the power factor, after compensation
*
by the active filter.
6 6
6-27
