How to Program

6.7 15-0* Operating Data

Parameter group containing filter information such as
operating data, hardware configuration and software
versions.
6.7.1 15-0* Operating Data
15-00 Operating Hours
Range: Function:
0 h [0 - 2147483647 h] View how many hours the unit has
*
run. The value is saved when the unit
is turned off.
15-01 Running Hours
Range: Function:
0 h [0 - 2147483647 View how many hours the filter has
*
h] run. Reset the counter in 15-07 Reset
Running Hours Counter. The value is
saved when the unit is turned off.
15-03 Power-ups
Range: Function:
0 [0 - 2147483647 ] View the number of times the unit has
*
been powered up.
15-04 Over Temps
Range: Function:
0 [0 - 65535 ] View the number of unit temperature faults
*
which have occurred.
15-05 Over Volts
Range: Function:
0 [0 - 65535 ] View the number of unit overvoltages which
*
have occurred.
15-07 Reset Running Hours Counter
Option: Function:
[0] Do not reset
*
[1] Reset counter Select Reset [1] and press [OK] to reset the
Running Hours counter to zero (see
15-01 Running Hours). This parameter cannot
be selected via the serial port, RS-485.
Select Do not reset [0] if no reset of the
Running Hours counter is desired.
6.7.2 15-1* Data Log Settings
The Data Log enables continuous logging of up to 4 data
sources (15-10 Logging Source) at individual rates
(15-11 Logging Interval). A trigger event (15-12 Trigger
VLT Active Filter AAF 00x
Event) and window (15-14 Samples Before Trigger) are used
to start and stop the logging conditionally.
[0]
[1600] Control Word
[1603] Status Word
[1630] DC Link Voltage
[1634] Heatsink Temp.
[1635] Inverter Thermal
[1660] Digital Input
[1666] Digital Output [bin]
[1690] Alarm Word
[1692] Warning Word
[1694] Ext. Status Word
Application
dependent
[0]
[1]
[2]
[6]
[16]
[19]
[20]
[21]
[33]
[34]
[35]
[36]
®
MG.90.V2.22 - VLT is a registered Danfoss trademark
15-10 Logging Source
Array [4]
Option: Function:
Select which variables are to be
logged.
None
*
15-11 Logging Interval
Range:
[Application
dependant]
*
15-12 Trigger Event
Select the trigger event. When the trigger event occurs, a
window is applied to freeze the log. The log will then retain a
specified percentage of samples before the occurrence of the
trigger event (15-14 Samples Before Trigger).
Option:
False
*
True
Running
Current limit
Thermal warning
Warning
Alarm (trip)
Alarm (trip lock)
Digital input DI18
Digital input DI19
Digital input DI27
Digital input DI29
Function:
Enter the interval in
milliseconds between each
sampling of the variables to
be logged.
Function:
6-19
