Danfoss VLT AAF00x Instruction Manual page 44

How to Install VLT Active Filter AAF 00x
The connector located on the power card provides the AC
line voltage connection for the cooling fans. The fans are
factory-equipped to be supplied from a common AC line
(jumpers between 100-102 and 101-103). If an external
supply is needed, the jumpers are removed and the supply
is connected to terminals 100 and 101. A 5 Amp fuse
should be used for protection. In UL applications this
4 4
should be LittelFuse KLK-5 or equivalent.
®
MG.90.V2.22 - VLT is a registered Danfoss trademark 4-31
