OpenVPN modes of operation

and requires public key infrastructure (PKI) to generate the certificates. When TLS is used, OpenVPN
works as follows:
1. Using PKI, the administrator generates a certificate and the associated files for each endpoint. All
certificates are "signed" by the certificate authority (CA) of the PKI. The certificate for an endpoint
contains many pieces of information, one of which is the name of the endpoint, which is stored in
the Common Name field of the certificate.
2. The administrator transfers each certificate and the associated files to the corresponding endpoint
by using a pre-established, secure channel (for example, SCP).
3. When two endpoints need to establish the VPN tunnel, one endpoint takes a passive role while the
other endpoint must take an active role and initiate the TLS session with the passive endpoint.
4. After the active endpoint initiates the TLS session, the two sides authenticate each other by using
their public-private key pairs and the public key of the CA, which is known to both endpoints.
5. After the two endpoints have authenticated each other, they establish a shared secret by using
public-key cryptography. Each endpoint then derives a set of keys for the session. As for the
preshared secret mechanism, these keys are then used for encryption and MAC on the tunnel data
to provide data confidentiality and integrity. However, unlike the preshared secret mechanism, these
keys are used only for the one session, and for this reason they are called "session keys."
Certificate generation and distribution using PKI involves numerous complex security issues, which
are outside the scope of this document.
OpenVPN modes of operation
OpenVPN supports both site-to-site and remote access operation. In addition, client-side remote
access support is available for accessing configuration information from an OpenVPN Access Server.
NOTE
If client-side access to OpenVPN Access Server is configured, all OpenVPN configuration parameters
other than those used to connect to OpenVPN Access Server (that is, those within the interfaces
openvpn vtunx remote-configuration command) are ignored.

Site-to-site operation

The following figure illustrates a simple site-to-site VPN operation. This operation could represent, for
example, a connection between a branch office and a data center.
