53-1003581-03
12 August 2015
Brocade ICX 7450,
Brocade ICX 7750, and
Brocade ICX 7250
Stacking
Deployment Guide
Supporting FastIron Software Release 08.0.30

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ICX 7450 and is the answer not in the manual?

Questions and answers

Related Manuals for Brocade Communications Systems ICX 7450

Summary of Contents for Brocade Communications Systems ICX 7450

  • Page 1 53-1003581-03 12 August 2015 Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide Supporting FastIron Software Release 08.0.30...
  • Page 2 United States government. The authors and Brocade Communications Systems, Inc. assume no liability or responsibility to any person or entity with respect to the accuracy of this document or any loss, cost, liability, or damages arising from the information contained herein or the computer programs that accompany it.

  • Page 3: Table Of Contents

    Use cases................... 55 Chapter 3: ICX7250 Stack................57 Technical Architecture.................57 Supported Topologies................. 60 Brocade ICX 7250 Stack Construction Methods.........65 Debugging and verification using show commands......77 Use Cases...................81 Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...

  • Page 4: Brocade Icx 7450, Brocade Icx 7750, And Brocade Icx 7250 Stacking

    Brocade offers a truly distributed architecture, where all the components can be spread across the entire Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...

  • Page 5: Overview

    Overview The Brocade ICX 7450, Brocade ICX 7250, and Brocade ICX 7750 are high density 1RU switches that can run switch or router code to provide full L2 and L3 functionality. They come in five different hardware SKUs .

  • Page 6: Chapter 1: Icx7450

    Chapter 1: ICX7450 Technical Architecture The Brocade ICX 7450 has five different models based on Port Density, PoE capability and Port type; in addition each of the SKU supports four different flex modules. The SKU types are as follows: 1. ICX7450-24 2.
  • Page 7 (60 W) and HDBase-T alliance's PoH (up to 95W) support is provided in the first eight ports. It has full wide hot-plug module slot in the front and two full wide hot-plug module slots in the back. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 8 Release 08.0.30, the Brocade ICX 7450 supports stacking on 4x10G modules as well. NOTE The ICX 7450 can support 4X10 GF stacking from slot 2 or 1x40GQ stacking from rear ports; however, it cannot support both in the same stack.
  • Page 9 When stacking is not enabled, ports x/2/1 and x/2/3 can be used as data/uplink ports. FIGURE 7 ICX 7450 Showing 4x10G Stacking Ports Stack can be formed using up to 12 units of any ICX 7450 model type as a liner topology or a ring topology.

  • Page 10: Supported Topologies

    The Brocade ICX 7450 can operate as a standalone device as well as a stackable device. When used as a stack, ICX 7450 supports linear and ring stack topologies. All different SKUs of ICX 7450 can be mixed in the same stack. The stack can be formed with two units and up to twelve units. Following are examples of some of the ICX 7450 stacks connected in linear and ring topologies using 1x40G stacking ports.
  • Page 11 8 unit stack linear and ring topology 8 unit stack linear and ring topology Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...

  • Page 12: Brocade Icx 7450 Stack Construction Methods With 1X40G Stacking Ports

    12 units can be connected. The example presented here for configuration is for 12 unit stack. Please refer to the Bill of Materials section later in this document for the software image, optics, and vendor information Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 13 1x40G ports to configure stacking TABLE 3 Optics information for the Brocade ICX7450 stacking QSFP Hardware Description BRCD Part Number 40G-QSFP-SR4 40GE SR 57-1000128-01 40G-QSFP-SR4 40GE SR 57-1000128-01 Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 14 2. Once stack enable is configured, this command will configure two default stack ports, 1/3/1 and 1/4/1 as seen in the message displayed. This can be confirmed using 'show run' command. ICX7450-24 Switch(config)#show running Current configuration: ver 08.0.20T213 Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 15 4. The user is prompted to enter 'y' to confirm unit IDs. If the user wants to enter different unit IDs, the user should enter 'n' instead of 'y.' This example log shows 'y' because acceptance was entered. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 16 PoE: Stack unit 7 Power supply 2 with 748000 mwatts capacity is up T:4m24.0: Done hot swap: active controller u1 sets u10 to Ready. T:4m25.5: Done hot swap: active controller u1 sets u11 to Ready. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 17 The example used below is 12 units to form a linear stack. Steps Manual stack formation: • Configure the highest priority on an intended active controller. • Configure second highest priority on an intended standby controller. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 18 Enable stacking. This unit actively participates in stacking stacking is enable. optical monitoring for stacking ports 1/3/1, 1/4/1 is not available. ICX7450-48F Router(config-unit-1)# UNIT 7: ICX7450-48P Router(config)#stack unit 1 Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 19 10 D ICX7450-48G member cc4e.246d.1838 0 remote Ready 11 D ICX7450-48P member cc4e.246d.23b8 0 remote Ready 12 D ICX7450-24P member cc4e.246d.0520 0 remote Ready active standby Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...

  • Page 20: Brocade Icx 7450 Stack Construction Methods With 4X10G Stacking Ports

    12-unit stack. Please refer to Bill of Materials, table 2 and table 3 for the software image, optics and vendor information. FIGURE 9 Brocade ICX 7450 three unit stack connected in linear topology using 4x10G stacking ports TABLE 4...
  • Page 21 Brocade proprietary discovery protocol that discovers units that are connected upstream and downstream from the switch where this command is entered, the intended Active controller. Steps Stack formation with secure setup utility: Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 22 4 icx7400-qsfp-1port-40g-module default-ports 1/2/1 1/2/3 --More--, next page: Space, next line: Return key, quit: Control-c^C ICX7450-24 Router(config)#exit ICX7450-24 Router#stack secure-setup ICX7450-24 Router#Discovering the stack topology... Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 23 Selected UPSTREAM units Hop(s) Type Mac Address ICX7450-48G cc4e.246d.1c78 ICX7450-48G cc4e.246d.1b78 ICX7450-48G cc4e.246d.1ff8 ICX7450-48P cc4e.2489.8640 ICX7450-48GF cc4e.246d.1478 ICX7450-48P cc4e.2489.b388 ICX7450-48P cc4e.2489.b188 ICX7450-48P cc4e.246d.2938 ICX7450-48G cc4e.246d.1838 Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 24 T=7m10.7: Election, was active, no change, ID=1, pri=128, 12U(1-12), A=u1, nbr#=11 0, reason: u12: port-up, , Detect stack unit 9 has different startup config flash, will synchronize it T=7m11.6: Synchronize webauth files to u9 Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 25 Stack unit 4 Power supply 1 is up Stack unit 4 Power supply 2 is down T=7m20.7: Synchronize startup config to u10 Flash Memory Write (8192 bytes per dot) . Write startup-config done. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 26 • Configure second highest priority on an intended standby controller. • Configure 'stack suggested-id' on the intended member units. • Configure 'stack enable' on all the units and connect the units using stack ports. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 27 ICX7450-48 Router(config-unit-1)#write memory ICX7450-48 Router(config-unit-1)#Flash Memory Write (8192 bytes per dot) . Write startup-config done. Copy Done. ICX7450-48 Router(config-unit-1)#stack enable Enable stacking. This unit actively participates in stacking Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 28 1/2/1, 1/2/3 is not available. UNIT 8: ICX7450-48P Router(config)#stack unit 1 ICX7450-48P Router(config-unit-1)#stack-trunk 1/2/1 to 1/2/2 ICX7450-48P Router(config-unit-1)#stack-trunk 1/2/3 to 1/2/4 ICX7450-48P Router(config-unit-1)#stack suggested-id 8 ICX7450-48P Router(config-unit-1)#write memory Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 29 6. After configuration connect the devices in a stack topology. The active controller retains its ID. The rest of the units are assigned unique ID numbers depending on the sequence in which they are Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...

  • Page 30: Debugging And Verification Using Show Commands

    | C |3/1--4/1| B |3/1--4/1| A |3/1--4/1| 9 |3/1--4/1| 8 |3/1--4/1| 7 |3/1- +---+ +---+ +---+ +---+ +---+ +---+ Standby u2 - protocols ready, can failover Current stack management MAC is cc4e.246c.ffd0 ICX7450-24 Router# Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 31 128 local Ready D ICX7450-48G standby cc4e.246d.1c78 0 remote Ready D ICX7450-48G member cc4e.246d.1b78 0 remote Ready D ICX7450-48G member cc4e.246d.1df8 0 remote Ready Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 32 +---+ +---+ +---+ +---+ +---+ +---+ +---+ | C |3/1--4/1| B |3/1--4/1| A |3/1--4/1| 9 |3/1--4/1| 8 |3/1--4/1| 7 |3/1- +---+ +---+ +---+ +---+ +---+ +---+ Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 33 Link 1: u1 -- u2, num=1 1: 1/4/1 (P1) <---> 2/3/1 (P0) Link 2: u2 -- u3, num=1 1: 2/4/1 (P1) <---> 3/3/1 (P0) Link 3: u3 -- u4, num=1 Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...

  • Page 34: Use Cases

    2. This new unit can then be connected to one of the end units using stack ports. 3. Active controller resets the new unit and upon boot up, the new unit is part of the stack. Do 'write memory'. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 35 • Replacing a stack unit with a clean stack unit • Replacing multiple stack units with multiple clean traditional stack units Steps Replacing one stack unit with a clean stack unit Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 36 4x10G stacking ports. 8. When the stack secure-setup utility is used to configure an ICX 7450 stack, end points or ports of the end units that are not used for stacking and that are link down are left as data ports except on...

  • Page 37: Chapter 2: Icx7750 Stack

    This hardware unit has 48 of 10G-BASE-T Copper ports on the front panel. These ports can work in 10G mode and use 10G-BASE-T auto negotiation with link partner. This can also work in 1G mode Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...

  • Page 38: Supported Topologies

    All different SKUs of ICX7750 can be mixed in the same stack. The stack can be formed with 2 units and can scale up to 12 units. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 39 The Brocade ICX7750 cannot be combined in a stack with other Brocade stackable devices. Only homogenous stack is supported. 2 unit stack linear and ring topology Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 40 4 unit stack linear and ring topology 4 unit stack linear and ring topology 8 unit stack linear and ring topology Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 41 12 unit stack linear and ring topology 12 unit stack linear and ring topology Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 42 Supported stacking combinations and trunking NOTE Users can use all front modules or all rear modules on all stack units for stacking. A mixed combination is not allowed. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...

  • Page 43: Brocade Icx7750 Stack Construction Methods

    12 units can be connected. The example configuration is for a 12 unit stack. Refer to the tables in the Bill of Materials section for the software image, optics, and vendor information. FIGURE 13 Front panel stacking ports Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 44 2. Connect 12 units in a linear/ ring topology. 3. Connect the using port default stacking port 1/2/1 and 1/2/4 on change to or1/3/1 and 1/3/4 on each unit. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 45 40G-QSFP-QSFP-C-0501 40GE QSFP Active Copper 5m 58-0000043-01 40G-QSFP-QSFP-C-0501 40GE QSFP Active Copper 5m 58-0000043-01 Per the manual LR4 optics are only supported on the following ports. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 46 To exit the secure-setup, enter ^C at any time. ICX7750-48F Switch# stack secure ICX7750-48F Switch# Discovering the stack topology... Current Discovered Topology - RING Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 47 ICX7750-48XGC cc4e.2439.1680 ICX7750-48XGC cc4e.2439.1d80 ICX7750-48XGC cc4e.2439.1280 Selected DOWNSTREAM units Hop(s) Type Mac Address ICX7750-48XGC cc4e.2439.1280 ICX7750-48XGC cc4e.2439.1d80 ICX7750-48XGC cc4e.2439.1680 ICX7750-48XGC cc4e.2439.1a00 ICX7750-20QXG cc4e.2439.2d00 ICX7750-20QXG cc4e.2439.3880 Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 48 T:3m9.0: Done hot swap: active controller u1 sets u12 to Ready. T:3m9.1: Done hot swap: active controller u1 sets u4 to Ready. T:3m9.2: Done hot swap: active controller u1 sets u8 to Ready. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 49 2. On a unit intended to be the active controller, configure the priority unit at 255. Configure the standby unit to be less than the priority (active) unit, for example, 240. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 50 ICX7750-48C Router(config-unit-1)#stack suggested-id 8 ICX7750-48C Router(config-unit-1)#stack enable Enable stacking. This unit actively participates in stacking stacking is enable. optical monitoring for stacking ports 1/2/1, 1/2/4 is not available. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...

  • Page 51: Debugging And Verification Using Show Commands

    0 remote Ready D ICX7750-48XGC member cc4e.2439.1a00 0 remote Ready 10 D ICX7750-48XGC member cc4e.2439.1680 0 remote Ready 11 D ICX7750-48XGC member cc4e.2439.1d80 0 remote Ready Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 52 (11/2/1-11/2/2 up (11/2/4-11/2/5 U12 (12/2/4-12/2/ U10 (10/2/1-10/2 up (12/2/1) up (12/2/4-12/2/5 U1 (1/2/4) U11 (11/2/1-11/2 Unit# System uptime 4 minutes 35 seconds 2 minutes 7 seconds Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 53 (10/2/4) up ports: 10/2/1, 10/2/2 up (11/2/1-11/2/2) up (11/2/4-11/2/5) up ports: 11/2/1, 11/2/2 up ports: 11/2/4, 11/2/5 up (12/2/1) up (12/2/4-12/2/5) up ports: 12/2/4, 12/2/5 Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 54 2: 6/2/2 (T0) <---> 7/2/5 (T1) 3: 6/2/3 (T0) <---> 7/2/6 (T1) Link 8: u7 -- u8, num=1 1: 7/2/1 (P0) <---> 8/2/4 (P1) Link 9: u8 -- u9, num=1 Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...

  • Page 55: Use Cases

    3. Active controller resets the new unit and upon boot up, the new unit is part of the stack. Do 'write memory'. Removing a unit from the stack Description Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 56 3. If you wanted this particular unit to replace unit 5, instead of unit 4, you must use secure-setup to select the ID of the old unit for the new unit. The active controller resets the unit, and upon boot up it joins the stack. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...

  • Page 57: Chapter 3: Icx7250 Stack

    This hardware unit has 24-Port RJ45 10/100/1000Mbps Ethernet port platform with EEE. In addition it has one fixed module providing 4x1F SFP uplink ports. The ICX7250-24G is not stackable. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 58 8x10G SFP+ ports, out of which 4x10F SFP+ can be configured as uplink ports and 4x10F SFP+ can be configured as stacking ports. FIGURE 19 ICX 7250-24P Front and Rear panel Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 59 1-Gbps mode. To form the stack again, the license must be downloaded to each device. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...

  • Page 60: Supported Topologies

    Any of these ports can be used for long-distance stacking if appropriate long-distance cables are used. Following are examples of some of the ICX7250 stack connected in linear and ring topologies. Two unit stack linear and ring topology Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 61 Four unit stack linear and ring topology Four unit stack linear and ring topology Eight unit stack linear and ring topology Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 62 Twelve unit stack linear and ring topology Twelve unit stack linear and ring topology Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 63 Supported stacking combinations and trunking Supported stacking combinations and trunking FIGURE 22 Supported cases FIGURE 23 Not supported cases Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 64 Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking FIGURE 24 Supported trunking cases Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...

  • Page 65: Brocade Icx 7250 Stack Construction Methods

    Similarly a stack of up to 12 units can be connected. The example presented here for configuration is for 12 unit stack. Please refer to Bill of Materials and the tables below for the software image, optics, and vendor information. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 66 Unit1 to Unit2 1/2/3 to 2/2/3 1/2/4 to 2/2/4 Unit2 to Unit3 2/2/1 to 3/2/1 2/2/2 to 3/2/2 Unit1 to Unit3 1/2/1 to 3/2/3 1/2/2 to 3/2/2 Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 67 The table below list the stacking connections of the stack in Figure 29 Unit # to Unit # Link Unit1 to Unit2 1/2/7 to 2/2/7 1/2/8 to 2/2/8 Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 68 'Stack secure setup' utility is the most convenient of all methods to form a stack. This utility uses a Brocade proprietary discovery protocol that discovers units that are connected upstream and downstream of the unit where this command is entered. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 69 Mac Address ICX7250-48P cc4e.24b4.2eb0 ICX7250-48P cc4e.24b4.2f28 ICX7250-24 cc4e.24b4.8988 ICX7250-48 cc4e.24b4.2820 ICX7250-48 cc4e.24b4.2514 ICX7250-24 cc4e.24b4.83a0 ICX7250-24 cc4e.24b4.8064 ICX7250-24 cc4e.24b4.84c0 ICX7250-24 cc4e.24b4.8670 ICX7250-24P cc4e.24b4.7efc ICX7250-24P cc4e.24b4.7bc0 Available DOWNSTREAM units Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 70 IDs. In this particular example log shows 'y' as acceptance was entered. Selected Topology: Active Type Mac Address ICX7250-24P cc4e.24b4.7c50 Selected UPSTREAM units Hop(s) Type Mac Address ICX7250-48P cc4e.24b4.2eb0 ICX7250-48P cc4e.24b4.2f28 ICX7250-24 cc4e.24b4.8988 ICX7250-48 cc4e.24b4.2820 ICX7250-48 cc4e.24b4.2514 Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 71 T=16m10.3: Synchronize webauth files to u9 T=16m10.4: Synchronize webauth files to u10 T=16m10.4: Synchronize webauth files to u11 Detect stack member 11 POE capable T=16m10.5: Synchronize webauth files to u12 Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 72 -2/3| 2 |2/1==2/1| 3 |2/3==2/1| 4 |2/3==2/1| 5 |2/3==2/3| 6 |2/1==2/1| 7 |2/3= +---+ +---+ +---+ +---+ +---+ +---+ Standby u2 - protocols ready, can failover Current stack management MAC is cc4e.24b4.7c50 ICX7250-24P Switch#write memory Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 73 In a live production environment, use the multi-stack-trunk command and use multi stack port command to remove change a stack trunk to stack. UNIT 1: ICX7250-24P Switch(config)#stack unit 1 ICX7250-24P Switch(config-unit-1)#priority 255 Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 74 ICX7250-48 Switch(config-unit-1)#stack enable Enable stacking. This unit actively participates in stacking stacking is enable. optical monitoring for stacking ports 1/2/1, 1/2/3 is not available. UNIT 9: Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 75 1/2/1, 1/2/3 is not available. UNIT 4: ICX7250-24 Switch(config)#stack unit 1 ICX7250-24 Switch(config-unit-1)#stack-trunk 1/2/1 to 1/2/2 ICX7250-24 Switch(config-unit-1)#stack-trunk 1/2/3 to 1/2/4 Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 76 Enable stacking. This unit actively participates in stacking stacking is enable. optical monitoring for stacking ports 1/2/1, 1/2/3 is not available. UNIT 11: ICX7250-48P Switch(config)#stack unit 1 ICX7250-48P Switch(config-unit-1)#stack-trunk 1/2/1 to 1/2/2 Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...

  • Page 77: Debugging And Verification Using Show Commands

    -2/3| C |2/1==2/1| B |2/3==2/1| A |2/3==2/1| 9 |2/3==2/3| 8 |2/1==2/1| 7 |2/3= +---+ +---+ +---+ +---+ +---+ +---+ Standby u2 - protocols ready, can failover Current stack management MAC is cc4e.24b4.7c50 ICX7250-24P Switch# Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 78 U12 (12/2/1-12/2/2) U10 (10/2/1-10/2/2) up (12/2/1-12/2/2) up (12/2/3) U11 (11/2/1-11/2/2) U1 (1/2/5) Unit# System uptime 38 minute(s) 50 second(s) 32 minute(s) 20 second(s) 23 minute(s) 22 second(s) Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 79 10/2/1, 10/2/2 up ports: 10/2/3, 10/2/4 up (11/2/1-11/2/2) up (11/2/3-11/2/4) up ports: 11/2/1, 11/2/2 up ports: 11/2/3, 11/2/4 up (12/2/1-12/2/2) up (12/2/3) up ports: 12/2/1, 12/2/2 Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 80 Link 10: u9 -- u10, num=2 1: 9/2/1 (T0) <---> 10/2/3 (T1) 2: 9/2/2 (T0) <---> 10/2/4 (T1) Link 11: u10 -- u11, num=2 1: 10/2/1 (T0) <---> 11/2/3 (T1) Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...

  • Page 81: Use Cases

    2. This new unit then can be connected to one of the end units using stack ports. 3. Active controller resets the new unit and upon boot up, the new unit is part of the stack. Do 'write memory'. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
  • Page 82 3. If you wanted this particular unit to replace unit 5, instead of unit 4, you must use secure-setup to select the ID of the old unit for the new unit. The active controller resets the unit, and upon boot up it joins the stack. Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...

  • Page 83: Related Documents

    7. When a uplink port is being converted to stacking ports, the uplink configuration should be removed before it can be configured as a stack port. Related documents Stacking Management Guide: http://my.brocade.com/wps/myportal/downloads Brocade ICX 7450, Brocade ICX 7750, and Brocade ICX 7250 Stacking Deployment Guide 53-1003581-03...
