OpenVPN Overview

●

OpenVPN security mechanisms..................................................................................... 13

● OpenVPN modes of operation........................................................................................ 14
OpenVPN security mechanisms
This section provides an introduction to the security mechanisms and modes of operation for OpenVPN
on the Brocade vRouter.

• Preshared secret

• TLS

The security requirements for a virtual private network include authentication, confidentiality, and
integrity. OpenVPN offers a choice of two different security mechanisms: preshared secret and
Transport Security Layer (TLS).
NOTE
Secure Sockets Layer (SSL) is the predecessor of TLS, and most current references to SSL are, in fact,
references to TLS. Therefore, these terms are used interchangeably in this document.
Preshared secret
When preshared secret is used for security, OpenVPN works as follows:
1. The administrator uses the generate vpn openvpn-key command to generate a file that contains a
certain number of random data bytes, that is, the secret to be used to provide security.
2. The administrator transfers the secret file to each of the two tunnel endpoints by using pre-
established secure channels. For example, the file can be generated on one of the endpoints and
then transferred to the other endpoint by using a secure file transfer protocol, such as SCP.
3. When the two endpoints need to establish the VPN tunnel, the OpenVPN process on the one
endpoint authenticates the other endpoint. Authentication is based on the assumption that the
preshared secret is known only to the other endpoint; that is, authentication is based on the
assumption that if any host knows the shared secret, that host must be the other endpoint.
4. After the endpoints are authenticated, the OpenVPN process on each side derives a set of keys from
the preshared secret. These keys are used for two purposes.
• Some keys are used in an encryption algorithm to encrypt the tunnel data. This encryption
• The others are used in a message authentication code (MAC) that uses a hash algorithm with the
TLS
Transport Layer Security (TLS) is a cryptographic protocol that uses public key cryptography and does
not require the two endpoints to have a preshared secret. OpenVPN uses TLS with X.509 certificates
Brocade 5600 vRouter OpenVPN Reference Guide
53-1003719-03
provides data confidentiality.
keys on the tunnel data. This code provides data integrity.
13
