Site-to-site mode with TLS

TABLE 4 Site-to-site OpenVPN with preshared secret: V2 static route (Continued)
Step
Show the static routing configuration.
Site-to-site mode with TLS
When TLS is used in site-to-site mode, the Brocade vRouter configuration is the same as described in
the previous section, except that you must configure TLS-related options instead of the shared-
secret-key-file option. As previously discussed, one endpoint takes the passive role and the other
takes the active role.
Each endpoint must also have the following files, which are required for the TLS protocol.
• Certificate Authority (CA) certificate file: This file contains the certificate of the CA, which is used to
validate the certificate of the other endpoint.
• Host certificate file: This file contains the certificate of the endpoint, which is presented to the other
endpoint during the TLS negotiation.
• Host key file: This file contains the private key of the endpoint, which is kept secret from anybody
else.
• Certificate revocation list (CRL) file: (Optional) This file contains a list of certificates that have been
revoked, which prevent endpoints with these certificates from establishing a VPN tunnel.
• DH parameters file: (Only needed by the passive endpoint) This file contains Diffie Hellman
parameters that are required only by the endpoint taking the passive role in the TLS negotiation.
More information about these files is available in the OpenVPN documentation.
The configuration that follows corresponds to the configuration for the example in the previous section.
Assume that the necessary files have been generated and distributed to each endpoint and that V1
and V2 are passive and active, respectively.
To configure V1 for a site-to-site VPN with TLS, perform the following steps in configuration mode.
TABLE 5 V1 OpenVPN configuration: site-to-site with TLS
Step
Create the vtun0 configuration node.
Set the local IP address of the VPN tunnel.
Set the OpenVPN mode.
Set the remote IP address of the VPN tunnel.
Specify the physical IP address of the remote host.
Set the role of this endpoint.
Specify the location of the CA certificate file.
Specify the location of the host certificate file.
22
Command
vyatta@V2# show protocols static
interface-route 192.168.100.0/24 {
next-hop-interface vtun0 {
}
}
Command
vyatta@V1# set interfaces openvpn vtun0
vyatta@V1# set interfaces openvpn vtun0 local-address
192.168.200.1
vyatta@V1# set interfaces openvpn vtun0 mode site-to-site
vyatta@V1# set interfaces openvpn vtun0 remote-address
192.168.200.2
vyatta@V1# set interfaces openvpn vtun0 remote-host 87.65.43.21
vyatta@V1# set interfaces openvpn vtun0 tls role passive
vyatta@V1# set interfaces openvpn vtun0 tls ca-cert-file /
config/auth/ca.crt
vyatta@V1# set interfaces openvpn vtun0 tls cert-file /config/
auth/V1.crt
