Feature
Battery Support
System Off Mode
UEFI Fast Boot
SATA Support
USB Support
Network Stack Driver Support
Redirection Support
UEFI Screenshot Capability
Note
The term 'AC power loss' stands for the state when the module looses the standby voltage on the 5V_SB pins. On congatec modules, the
standby voltage is continuously monitored after the system is turned off. If the standby voltage is not detected within 30 seconds, this is
considered an AC power loss condition. If the standby voltage remains stable for 30 seconds, it is assumed that the system was switched off
properly.
Inexpensive ATX power supplies often have problems with short AC power sags. When using these ATX power supplies it is possible that
the system turns off but does not switch back on, even when the PS_ON# signal is asserted correctly by the module. In this case, the internal
circuitry of the ATX power supply has become confused. Usually, another AC power off/on cycle is necessary to recover from this situation.
Copyright © 2016 congatec AG
Options
Description
Auto (Batt. Manager)
'Battery-Only On I2C Bus' - Battery-only systems using I2C bus.
Battery-Only On I2C Bus
'Battery-Only On SMBus' - Battery-only systems using SMBus.
'Auto' - Real battery system manager systems using I2C or SMBus.
Battery-Only On SMBus
G3/Mech Off
Set system state after shutdown if a battery system is present.
S5/Soft Off
Disabled
Enable to boot with a minimum set of devices.
Note: This feature has no effect for BBS / legacy boot options.
Enabled
Select SATA support.
Last Boot HDD Only
All SATA Devices
Disabled
'Disabled' - The USB devices will not be available before operating system boot.
Full Init
'Full Init' - All USB devices will be available during POST and after operating system boot.
Partial Init
'Partial Init' - Specific USB ports/devices will not be available before operating system boot.
Disabled
Disable to skip the UEFI network stack driver installation.
Enabled
Disabled
Disable to deactivate the Redirection function.
Enabled
Disabled
Enable this feature to take a screenshots from the current screen by pressing LCtrl+LAlt+F12.
Enabled
The image will be saved as PNG on the first writable FAT32 partition found.
ICSLm13.indd
92/95
