5.3.3

PCI Express Routing

The diagram below shows how the PCIe lanes are routed to the PCIe connectors.

PCIe Lane1

PCIe Lane2

PCIe Lane3

PCIe Lane4

PCIe Lane9

USB 2.0 Signals

PCIe Lane11

PCIe Lane12 or SATA port 2

USB 2.0 Signals

ICSLm13.indd

PCIe x4

Slot 0

Mini PCIe

Slot 1

M.2 Connector

Slot 2

X10

30/95
