9. Disable the generator output.
10. Reverse the probe input leads to the generator.
11. Invert the signal and trigger slope on the oscilloscope to display the rising edge of the signal.
12. Enable the generator output and make the adjustments in the following order: long-term –LF, long-term –LF*, short-term
–LF. (The long-term –LF* adjustment is not used in the P5202A probe.) Repeat this sequence as necessary to optimize
the square-wave response.
13. Disable the generator output.
Table 18: LF compensation test equipment settings
Model
P5200A
P5202A
P5205A
P5210A
P5200A Series High Voltage Differential Probes Instruction Manual
Probe
Range
50X
20X
50X
100X
Generator fast-rise output
Voltage (p-p)
50 V
50 V
50 V
50 V
Adjustments
Frequency
10 kHz
10 kHz
10 kHz
10 kHz
