Equipment Required - Tektronix P5200A Instruction Manual

Adjustments

Equipment Required

The equipment required to perform the adjustment procedures are shown in the table below. The types and quantities of
connectors may vary depending on the specific equipment you use.
Table 15: Equipment required for adjustments
Description
Oscilloscope
Generator
TekProbe power supply
Digital Multimeter (DMM)
Cable
Adapter
Adapter
Adapter
Probe hook tips (2)
Adapter 1
Adjustment tool
Adjustment tool 2
Replacement rear-panel
label 3 4
1
Not required for P5200A probe
2 Required for the CMRR adjustment
3
The original label is backed with a reusable adhesive. If the label does not sufficiently adhere to the probe, order a replacement.
4
Label removal is not required to access offset zero adjustments
WARNING. These procedures require you to remove a reusable label from the back of the probe. You must replace
the label after you complete the probe adjustments. Failure to do so may subject the user to high voltages present in
the probe during measurements.
43
Minimum requirements
500 MHz
±100 V variable, 100 Hz square wave, calibrated
1 TekProbe inputs
100 mV and 1 V true RMS AC ranges, <±0.3 %
accuracy
Coax, BNC, 50 Ω, 36 in
BNC male-to-dual binding post
BNC female-to-SMA male
BNC male-to-dual banana male
Included with probe accessory kit
TekVPI-to-BNC
Insulated, slotted (straight) head
Insulated, narrow-slotted (straight) head
Reusable, adhesive-backed label that covers
adjustment access openings
Example product
Tektronix MSO/DSO4000
Fluke 9100
Tektronix 1103
Tektronix DMM4040/4050
Tektronix part number 012-0482-xx
Tektronix part number 103-0035-xx
Tektronix part number 015-1018-xx
Fluke PM9081
Tektronix part number AC280–FL
Tektronix TPA-BNC
Tektronix part number 003-1433-xx
Tektronix part number 003-1928-xx
Tektronix part number 335-2913-xx
