Specifications; Warranted Specifications - Tektronix P5200A Instruction Manual

Specifications
The specifications shown apply to the P5200A Series probes installed on Tektronix MSO/DSO4000 oscilloscopes. When a
probe is used with another oscilloscope, the oscilloscope must have an input impedance of 1 MΩ and a bandwidth equal
to or greater than the probe. The probe must have a warm-up period of at least 20 minutes and be in an environment
that does not exceed the limits described. (See Table 5.) The probe calibration should be run on the host instrument
before verifying the warranted probe specifications. Specifications for the P5200A Series probes fall into three categories:
warranted, typical, and nominal characteristics.
Warranted Specifications
Warranted characteristics describe guaranteed performance within tolerance limits or certain type-tested requirements.
(See Table 4.)
Table 4: Warranted electrical specifications
Specification
Rise time
(small signal, 10–90%,
+20 °C to +30 °C)
Gain accuracy
1
Output may be slew rate limited for large amplitude signals.
Table 5: Warranted environmental specifications
Specification
Temperature
Operating
Nonoperating
Humidity
Operating
Nonoperating
Altitude
Operating
Nonoperating
P5200A Series High Voltage Differential Probes Instruction Manual
P5200A P5202A
≤7.0 ns ≤3.5 ns
≥240 V/ns (200X))
P5200A P5202A
–30° C to +70° C (–22 °F to +158 °F)
5 to 85% RH (Relative Humidity) 0 °C to +40 °C (32 °F to +104 °F)
5% to 85% RH at up to +40° C (+104 °F)
5% to 45% RH above +40° C up to +70° C (+104 to +158 °F)
P5205A
1 (slew rate ≤3.5 ns 1
≥590 V/ns (500X))
±2%
P5205A
0 °C to 40 °C (32 °F to +104 °F)
3,000 m (10,000 ft)
up to 15,240 m (50,000 ft)
Specifications
P5210A
(slew rate ≤7.0 ns
P5210A
28
