Tektronix P5200A Instruction Manual page 28

Accessories
P5200A, P5202A, & P5205A Probe Standard Accessories
Extender Leads
These cables extend the reach of the probes
by ~67 in (1.5 m). The banana ends connect
to all of the clip accessories that are included
with the probes.
One pair of extender leads are included with
the probes.
Maximum ratings:
2300 V CAT I *
1000 V CAT III
* See Specifications for the Over-Voltage
Transient (OVT) rating for the probe that you
are using.
Reorder Tektronix part number:
196-3523-xx (one pair)
Hook Clips (AC280-FL)
Plug the probe test leads into the banana
plug connectors. Squeeze the grips to
expose the hook clip and then clasp it around
the circuit test point.
Maximum ratings:
1000 V CAT III
600 V CAT IV
One pair of hook clips is included with the
probes.
Reorder Tektronix part number:
AC280-FL (one pair)
9 P5200A Series High Voltage Differential Probes Instruction Manual
