Adjustments

Adjustments
Use the following procedures to make adjustments to the P5200A Series probes. (For probes with serial numbers C019999
and below, see note and table that follow.) These procedures describe how to make adjustments to the specifications
listed below.
NOTE. Only probes with serial numbers C020000 and above have internal adjustments. (See Table 14.) Probes with serial
numbers C019999 and below, that require adjustments (other than offset zero), must be returned to Tektronix for service.
Table 14: P5200A Series probe adjustments
Specification
Offset zero
Gain accuracy
DC CMRR
LF compensation
AC CMRR
1
P5200A probe does not require comp box adjustment
NOTE. The adjustments in the probes are preset at the factory for best overall performance. However, you may follow these
procedures to check the probe characteristics and optimize them if necessary.
41
Adjustment method used
External; user probe controls and comp
box adjustment 1
Internal; adjustments on PCB
Internal; adjustments on PCB
Internal; adjustments on PCB
Internal; adjustments on PCB
P5200A Series High Voltage Differential Probes Instruction Manual
Probe serial number
All serial numbers
Serial numbers C020000 and above
Serial numbers C020000 and above
Serial numbers C020000 and above
Serial numbers C020000 and above
