Accessories
Table 2: Voltage derating for P5200A Series probes optional accessories
Accessory
Handheld probes
3
(TP175-FL)
Pogo pin tip adapters with either style tips
(020-3107-xx)
Extended test probe adapters
(012-1724-xx)
Crocodile clips
(344-0670-xx)
1
The operating altitude of the probe is derated to 2000 m (6560 ft) when used with these accessories.
2
The voltage rating and CAT rating are derated to the voltage in this table when used with these accessories.
3
When using the TP175-FL test probes in CAT III circuits, the tip must be in the retracted position to prevent risk of arc flash. The exposed metal tip
is about 3.7 mm (0.15 in) in the retracted position.
19
Combined probe and accessory common-mode voltage
and input voltage-to-earth ratings
P5202A
P5200A & P5205A
450 V CAT I
1000 V CAT II
300 V CAT II
600 V CAT III
150 V CAT II
150 V CAT II
300 V CAT I
300 V CAT II
300 V CAT II
450 V CAT I
1000 V CAT II
300 V CAT II
600 V CAT III
P5200A Series High Voltage Differential Probes Instruction Manual
1
,
2
P5210A
1000 V CAT I
1000 V CAT III
150 V CAT II
300 V CAT I
300 V CAT II
1000 V CAT I
1000 V CAT III
