9. Set the probe attenuation to the next range and set the generator output voltage to the value shown in the table.
10. Enable the generator output and adjust the high-range DC gain pot in the probe to ≤2% of the expected output.
11. Disable the generator output.
Table 16: Adjust gain accuracy equipment settings
Probe
Model Range
P5200A 50X
500X
P5202A 20X
200X
P5205A 50X
500X
P5210A 100X
1000X
P5200A Series High Voltage Differential Probes Instruction Manual
Generator square wave output
Voltage (rms) Frequency
25 V 100 Hz
75 V 100 Hz
20 V 100 Hz
60 V 100 Hz
25 V 100 Hz
75 V 100 Hz
75 V 100 Hz
75 V 100 Hz
Probe output voltage
Expected (rms) Measured (rms)
500 mV ±10 mV
150 mV ±3 mV
1.0 V ±20 mV
300 mV ±6 mV
500 mV ±10 mV
150 mV ±3 mV
750 mV ±15 mV
75 mV ±1.5 mV
Adjustments
