Tektronix P5200A Instruction Manual page 49

Table 7: Typical electrical specifications
Specification
Bandwidth (-3 dB)
Offset zero
(+20 °C to +30 °C)
Input resistance
Between inputs
Between each input
and ground
Input capacitance
Between inputs
Between each input
and ground
Common Mode
Rejection Ratio
(20–30°C)
Propagation delay
DC offset drift (output
referred)
Bandwidth limit filters
Input overdrive recovery
Rated power input
(P5200A only)
Voltage
Current
AC adapter
(P5200A only)
Input voltage
Frequency
Output voltage and
current
P5200A Series High Voltage Differential Probes Instruction Manual
P5200A P5202A
DC to 50 MHz DC to 100 MHz
±10 mV ±200 mV (20X)
(50X & 500X)
±2 V (200X)
output referred input referred
10 MΩ ±2% 5 MΩ ±2%
5 MΩ ±2% 2.5 MΩ ±2%
<2.0 pF <2.0 pF
<4.0 pF per side <4.0 pF per side
DC: >80 dB DC: >80 dB
100 kHz: >60 dB 100 kHz: >60 dB
3.2 MHz: >30 dB 3.2 MHz: >30 dB
50 MHz: >26 dB 100 MHz: >26 dB
21 ns 18 ns
5 MHz filter 5 MHz filter
<20 ns to 10% of <20 ns to 10% of
final value after final value after
5X overdrive (1/50 5X overdrive (1/20
gain) gain)
9 VDC
750 mA Max
—
100 - 240 VAC
—
50 - 60 Hz
—
9 VDC/ 2 A
P5205A
DC to 100 MHz
±500 mV (50X)
±5 V (500X)
input referred
10 MΩ ±2%
5 MΩ ±2%
<2.0 pF
<4.0 pF per side
DC: >80 dB
100 kHz: >60 dB
3.2 MHz: >30 dB
100 MHz: >26 dB
18 ns
50 μV/ °C
5 MHz filter
<20 ns to 10% of
final value after
5X overdrive (1/50
gain)
—
—
—
Specifications
P5210A
DC to 50 MHz
±1 V (100X)
±10 V (1000X)
input referred
40 MΩ ±2%
20 MΩ ±2%
<2.5 pF
<5.0 pF per side
DC: >80 dB
100 kHz: >60 dB
3.2 MHz: >30 dB
50 MHz: >26 dB
18 ns
5 MHz filter
<30 ns to 10% of
final value after 5X
overdrive (1/100
gain)
—
—
—
30
