Connectors
7.4
USB OTG HS micro-AB connector CN12
Pin number
1
2
3
7.5
Ethernet RJ45 connector CN9
22/49
Figure 15. USB OTG micro-AB connector CN12 (front view)
Table 4. USB OTG HS micro-AB CN12
Description
VBUS
D-
D+
Figure 16. Ethernet RJ45 connector CN9 (front view)
DocID027942 Rev 3
Pin number
Description
4
5
-
UM1907
ID
GND
-
