5.8.2 Adv. Drive Statistics

The Adv. Drive Statistics tab shows S.M.A.R.T. (Self-Monitoring, Analysis and
Reporting Technology) information taken directly from what the drive is
reporting. Navigate between drives by using the left and right scroll arrows. The
up and down scroll arrows scroll through the different information. The
information shown is the raw value tracked by the drive and is not translated.

5.8.3 Network Interface Stats

This screen displays the Network Interface statistics (Receive and Transfer bytes,
packets, drops, errors, and the link status).

5.8.4 Debug Logs

There may be times when Logicube Technical Support will ask for debug logs.
This tab allows the user to export the debug logs to a USB flash drive (connected
to one of the two front USB ports).

5.8.5 Help

The help tab contains a QR code that links to the user's manual online. There are
several ways to view the manual through the QR code such as:
•
•
•

5.9 Manage Repositories

Repositories can be added to the Falcon-NEO using this operation.
When Manage Repositories is selected, three tabs are available at the top of
the screen:
Add/Remove (using the SMB (Server Message Block) or CIFS (Common Internet File
•
System) protocol
iSCSI (Internet Small Computer System Interface protocol)
•
Configuration
•
The following information is required to set up an SMB/CIFS repository:
Path – Also called the Network Path (The IP address/Hostname and sharename).
•
Logicube Falcon -Neo User's Manual
®
From the touch screen (if the Falcon-NEO is connected to a network with
Internet access), simply tap the QR code.
Through a web browser, when using the web interface (see
for more information on the web interface), click the QR code.
Scan the QR code from a mobile phone or tablet that has internet access.
TYPES OF OPERATIONS
Section 9.1
72
