F – Up and down scroll arrows
G – Operations options and settings
H – Start icon

2.4 Front and rear ports

The Falcon-NEO has two USB host ports, two 10GbE ports, and two DC IN power ports.

2.4.1 Front ports

The Falcon-NEO has two USB host ports. These ports are used to connect
peripherals such as USB keyboards, mice, and printers. These ports are also used
for exporting audit log and debug log files.

2.4.2 Rear ports

The Falcon-NEO has two DC IN power ports, two 10GbE ports, and an HDMI port.
Logicube Falcon -Neo User's Manual
®

2.4.2.1 DC IN power ports

The Falcon-NEO has two DC IN ports. The included AC
adapter/power supply can be connected to either DC IN port and
will provide power to the Falcon-NEO. There are two DC IN ports
for possible future power scaling requirements.

2.4.2.2 Dual 10GbE ports

The Falcon-NEO has two 10GbE (Gigabit Ethernet) ports (labeled
LAN_1 and LAN_2) to provide fast network performance. Some of
the possible uses for these ports include (but are not limited to)
the following:
Connect two NAS devices to each port.
•
Connect a NAS to one port and the suspect's network to
•
the other.
Connect a work network (to control the Falcon-NEO
•
remotely) and a NAS to the other port.

2.4.2.3 HDMI

The Falcon-NEO has a standard Type A HDMI port located in the
back panel. Simply connect an HDMI cable from the Falcon-NEO
to an external display that supports HDMI and the Falcon-NEO
will automatically show the display on both the Falcon-NEO and
the external display.
To change the display resolution on the external display:
