Logicube Falcon -Neo User's Manual
®
Details on each selectable option on the Image
screen can be found in
Select Imaging from the types of operation on the left side.
Tap the Mode icon and select one of the six modes then tap the OK icon.
Tap the Source icon and choose the source from the list of connected
drives then tap the OK icon.
Tap the Settings icon and adjust the settings as needed (Case Info, File
Image Method Settings or Mirror Settings, HPA/DCO, Error Handling,
Hash/Verification Method, etc.) then tap the OK icon.
The Settings screen will be different for each of
•
the two modes. Details on the different Settings
screens can be found in
Log file names can be set in Settings in the Case
•
Info screen by entering a Case/File name. See
Section 4.3.1
The Falcon-NEO will convert any non-POSIX portable
characters used in Case/File Name field to
underscores (_) when creating the log or file names.
POSIX portable characters are:
Uppercase A to Z
Lowercase a to z
Numbers 0 to 9
Tap the Destination icon and select the destination(s) to be used then
tap the OK icon.
For DD, E01, Ex01, and DMG, the Falcon-NEO must
be used to format drives. If the Destination drive is
not formatted by the Falcon-NEO, the Location
will appear as "(NOT_MOUNTED)" and a format
icon will appear in the Format column. Tap the
(Format) icon to format the Destination drive.
Encrypted drives will have the following symbol in
the Format column:
Tap the Start icon to start the imaging task.
A progress bar will appear at the bottom of the screen showing the bytes
processed, the rate (speed), elapsed time, and time remaining.
Chapter 4: Imaging.
Chapter 4:
for more information.
Period (.)
Underscore (_)
Hyphen/Dash (-)
QUICK START
Imaging.
16
