Chapter 17
Applying NAT
Using Dynamic NAT and PAT
192.168.1.1-192.168.2.254
For example, to translate the 10.1.1.0/24 network on the inside interface, enter the following command:
hostname(config)# nat (inside) 1 10.1.1.0 255.255.255.0
hostname(config)# global (outside) 1 209.165.201.1-209.165.201.30
To identify a pool of addresses for dynamic NAT as well as a PAT address for when the NAT pool is
exhausted, enter the following commands:
hostname(config)# nat (inside) 1 10.1.1.0 255.255.255.0
hostname(config)# global (outside) 1 209.165.201.5
hostname(config)# global (outside) 1 209.165.201.10-209.165.201.20
To translate the lower security dmz network addresses so they appear to be on the same network as the
inside network (10.1.1.0), for example, to simplify routing, enter the following commands:
hostname(config)# nat (dmz) 1 10.1.2.0 255.255.255.0 outside dns
hostname(config)# global (inside) 1 10.1.1.45
To identify a single real address with two different destination addresses using policy NAT, enter the
following commands (see
Figure 17-8 on page 17-10
for a related figure):
hostname(config)# access-list NET1 permit ip 10.1.2.0 255.255.255.0 209.165.201.0
255.255.255.224
hostname(config)# access-list NET2 permit ip 10.1.2.0 255.255.255.0 209.165.200.224
255.255.255.224
hostname(config)# nat (inside) 1 access-list NET1 tcp 0 2000 udp 10000
hostname(config)# global (outside) 1 209.165.202.129
hostname(config)# nat (inside) 2 access-list NET2 tcp 1000 500 udp 2000
hostname(config)# global (outside) 2 209.165.202.130
To identify a single real address/destination address pair that use different ports using policy NAT, enter
the following commands (see
Figure 17-9 on page 17-11
for a related figure):
hostname(config)# access-list WEB permit tcp 10.1.2.0 255.255.255.0 209.165.201.11
255.255.255.255 eq 80
hostname(config)# access-list TELNET permit tcp 10.1.2.0 255.255.255.0 209.165.201.11
255.255.255.255 eq 23
hostname(config)# nat (inside) 1 access-list WEB
hostname(config)# global (outside) 1 209.165.202.129
hostname(config)# nat (inside) 2 access-list TELNET
hostname(config)# global (outside) 2 209.165.202.130
Cisco Security Appliance Command Line Configuration Guide
17-24
OL-10088-01
