Proservo NMS5
Endress+Hauser
12

Technical Data

Measuring Range
Density Limits
Accuracy
Sensitivity
Self-diagnostic Function
Input/Output
Motion Delay
Power
Max. Current
Surge Protection
Ambient Temperature
Liquid Temperature
Displacer Speed
Display
Operation
Calibration
Weight
Protection Class
Ex Approval
Additional Certificates
Color
Supplementary Documentation
*1
PTB reference conditions
*2
Difference of product densities at least 0.100 g/cm
*3
Optional when calibrated for density measurement
0 to 16, 28, or 36m depending on material specification
(longer ranges available upon consultation)
3
0.430 to 2.000 g/cm (430 to 2000 kg/m
*1
Level: +/- 0.7mm (0.027 inch)
Interface: +/- 2.7mm (0.106 inch)
3 *3
Density: +/- 0.005 g/cm
+/- 0.1mm (0.004 inch)
CPU system health, measuring wire tension, communication, gauge status, level
data input, etc
see Ordering Information
Configurable in 20ms steps from 0 to 9.9 seconds
85 to 264 VAC, 50/60 Hz
20 to 62 VDC, or 20 to 55 VAC, 50/60Hz
50VA / 50W
Standard supply
-20 to 60 ºC (-4 to 140ºF)
-40 to 60 ºC (-40 to 140ºF) ATEX approval cold temperature version
-200 to +200ºC (-328 to +392ºF)
Max. 2500mm/min
Backlight LCD, level, temperature, status, diagnostics, menu-navigation, in English,
Japanese and Chinese
Local operation by optical display keypad, external contact
Optical display keypad for tank level and sensor adjustment by automated software
routine
12kg (Aluminum drum housing NMS5-1, 5-4)
27kg (Stainless steel drum housing NMS5-2, 5-5, 5-6)
IP67 / NEMA4X
IEC Ex d [ia] IIB T6...T3 Ga/Gb
IEC Ex d IIB T6...T3 Ga/Gb
IEC Ex d IIC T6...T3 Ga/Gb
ATEX II 1/2G Ex d IIB T6...T3
ATEX II 1/2G Ex d [ia] IIB T6...T3
ATEX II 1/2G Ex d IIC T6...T3
FM XP-AIS Cl.I Div.1 Gr.C-D
FM XP Cl. I Div.1 Gr.C-D
CSA Cl. I Div.1 Gr.C-D
CSA Ex d [ia] Cl. I Div.1 Gr.C-D
TIIS Ex d IIB T4
Weights and Measures for custody transfer : NMi, PTB
Overspill prevention : TÜV Nord
SIL (Functional Safety Manual): TÜV Nord
Body: blue (RAL5012); Covers: white (RAL7035)
• Technical Information (TI00452G)
• Installation Instruction (BA00401G)
• Safety Instruction (XA00578G...ATEX, XA00582G...IECEx)
• Functional Safety Manual (SD00337G)
3
12 Technical Data
3
)
*2
105
