9 Accessories
80
9.3
Ball Valve NHV4A
NHV4A: Standard ball valve with ANSI flanges
NHV4J: Standard ball valve with JIS flanges
Figure. 81: Ball Valve
9.4
Reducing Flange NHF4
Low pressure (JPI example)
Stud Bolt
Flange
Figure. 82: Reducing Flange
153
Body cap
Ball
Body
Stud Bolt
Flange
Proservo NMS5
High pressure (ANSI example)
