Proservo NMS5
Endress+Hauser
Displacer
Symbol
Status
BAL
T - B
U - U
U - D
R - U
R - D
LOW
Note!
If no LCD operation, NMS5 will turn off the backlight of LCD 12 hour later. Touching LCD again after this
time will turn on the backlight.
Balance
The displacer is resting on the liquid surface or interface and in bal-
anced status.
Temporary Balance
Automatic weight calibration is being carried out.
Unbalance Up
The displacer is being hoisted and in unbalanced status.
Unbalance Down
The displacer is being lowered and in unbalanced status.
Balance Up
The displacer is being hoisted and in correction of balance.
Balance down
The displacer is being lowered and in correction of balance.
The displacer is resting at the lower stop.
6 Operation
Meaning
