Proservo NMS5
Endress+Hauser
Weight Table Calibration and Density
Item
50.x g
Wire Drum
weight
e.g.
300.110
Service
Matrix: G3
H
V
4
H
V
51
ACCESS CODE
7
Figure. 101: Calibration 1-B
Figure. 102: Calibration 2-B
Procedure
1. Set Access Code at 51
Displacer
and confirm the
following data.
e.g.
250.2 g
• G3V4H0 wire Drum
Circum.(engraved on
wire drum)
0 1 2
• G3V4H1 Wire
xxx.xxx x.xx xxx.x
Weight Standard
9
SUS = 1.40
50.2
PFA=4.55
Hastelloy=2.48
• G3V4H2 Displacer
Weight (engraved on
displacer)
• G3V7H9 Zero Adjust
Weght = e.g. 50.2
2. Confirm each engraved
data in the wire drum
and the displacer and
values in Matrix are the
same.
3. Displacer is located in
the calibration window
or the maintenance
chamber.
Set Operation = STOP
Set G3V7H9=e.g.
50.2g (test weight, in
grams)
Set G3V7H3 Weight
Calib. =ON
4. Enter No "-" key at
"Low weight set?" cali-
bration window and
enter Yes "+" key for
maintenance
chamber.
11 Displacer and Measuring Wire
Remarks
103
