14 Appendix
158
14.3.3 Displacers
Actual draft position may change slightly with tank parameters.
Ø30mm SUS Cylindrical
Ø 30 mm
Ø40mm SUS Cylindrical
Ø 40mm
Figure. 113: Dimension of Displacer 1
Weight 261g
3
Volume 85cm
Balance volume 3
41.3cm
Draft point
63.8mm
Draft Point
Ø 30 mm
Ø40mm PTFE Cylindrical
Weight 254g
3
Volume 152cm
Balance volume
71.1cm 3
Draft point
64.1mm
Draft Point
Ø 40mm
Proservo NMS5
Ø30mm PTFE Cylindrical
Ø 11mm
Weight
Volume
Balance volume
Draft point
Draft Point
Ø 11mm
Weight
Volume
Balance volume
Draft point
Draft Point
Endress+Hauser
240g
3
108cm
53.7cm 3
79.5mm
280g
126cm 3
3
62.6cm
54.5mm
