7 Commissioning
56
7.1.7 Analogue Output (GVH250 to 256)
When specified and ordered from Endress+Hauser, NMS5 is equipped with analogue output hardware
installed. Function settings may be changed as follows:
Function
Assign Output 1 Assign level or temperature to channel 1 output.
Adjust 4mA Set desired value at which level or temperature outputs 4 mA.
Adjust 20mA Set desired value at which level or temperature outputs 20 mA
Assign Output 2 Assign level or temperature to channel 2 output.
Adjust 4mA Set desired value at which level or temperature outputs 4 mA
Adjust 20mA Set desired value at which level or temperature outputs 20 mA.
Device at Alarm Select type of output for alarm
7.1.8 Contact Relay Alarm Output (GVH240 to 247)
When specified and ordered from Endress+Hauser, NMS5 is equipped with contact relay alarm output hard-
ware installed. Function settings may be changed as follows:
Function
Select Relay Select relay number from 1, 2, 3 or 4.
Assign Relay Select output definition from range of choices: None, Level, Liquid
Temperature, Caution, Warning, Emergency Error, Balance Signal.
Relay Function Select High or Low.
Switching Point Set value at which relay is activated.
Hysteresis Set hysteresis value for selected relay.
Relay on Alarm Select relay of Normal Open or Normal Closed.
On Delay Time Set time delay value for alarm output start.
Off Delay Time Set delay value for alarm output stop.
