Proservo NMS5
Endress+Hauser
Figure. 66: Level Calibration 2
5.
Set Level Calibration to 45mm at GVH150 (SET LEVEL) in G1 MATRIX (Calibration).The bottom is
ZERO.
• If the bottom plate is not Zero (ex; X mm), adjust the level value by adding to the value.
LEVEL = X + 45(mm)
This completes the level calibration procedure.
7 Commissioning
45mm
45mm
0mm
61
