2 Identification
12
2.2

Ordering Structure

010 Drum Housing Pressure Rating; Material:
1
0... 200mbar/20kPa/2.9psi; Alu
2
0... 200mbar/20kPa/2.9psi; stainless ste>
4
0... 5.88bar/588kPa/85.28psi; Alu
5
0... 5.88bar/588kPa/85.28psi; stainless steel
6
0... 24.5bar/2.45MPa/355.34psi; stainless steel
9 Special version, TSP-no. to be spec.
020 Approval:
0 Weather proof, IP 67 NEMA 4X
1 TIIS Ex d IIB T4
5 FM XP Cl. I Div. 1 Gr. C-D
N FM XP-AIS Cl. I Div.1 Gr. C-D
6 CSA Cl. I Div. 1 Gr. C-D
O CSA Ex d[ia] Cl. I Div. 1 Gr. C-D
G ATEX II 1/2G Ex d IIB T6...T3
Q ATEX II 1/2G Ex d IIC T6...T3
S ATEX II 1/2G Ex d IIB T6...T3, -40°C
J ATEX II 1/2G Ex d (ia) IIB T6...T3
U ATEX II 1/2G Ex d (ia) IIB T6...T3, -40°C
A IEC Ex d ia IIB T6...T3 Ga/Gb
B IEC Ex d IIB T6...T3 Ga/Gb
C IEC Ex d IIC T6...T3 Ga/Gb
D IEC Ex d ia IIB T6...T3 Ga/Gb, -40°C
E IEC Ex d IIB T6...T3 Ga/Gb, -40°C
9 Special version, TSP-no. to be spec.
030 Application:
A Liquid Level
B PTB (<1mm) type approval, liquid level
C NMi (<1mm) type approval, liquid level
D Multi measurement, liquid level, I/F level, bottom, density
E PTB (<1mm) type approval, liquid level, I/F level, bottom, density
F NMi (<1mm) type approval, liquid level, I/F level, bottom, density
G Density profile multi measurement, liquid level, I/F level, bottom, density
H PTB (<1mm)type approval, density profile, liquid level, I/F level, bottom, density
J NMi (<1mm) type approval, density profile, liquid level, I/F level, bottom, density
Y Special version, TSP-no. to be spec.
040 Output 1:
F Not selected
A 2-way 2-wire (V1 protocol)
J 2-way 2-wire (MDP protocol)
B 2-way 2-wire (BBB protocol)
C 2-way 2-wire (MIC, RS232C protocol)
D 2-way 2-wire (MIC protocol)
G HART active
H HART passive
L Whessmatic 550, overvoltage protection
M Mark Space
N Enraf BPM
P Modbus RS 485
Y Special version, TSP-no. to be spec.
050 Output 2:
0 Not selected
1 4 x relay SPST
2 2 x 4-20mA
3 4 x relay SPST, 2 x 4 - 20mA
4 2 x relay SPST, Overspill prevention TÜV
5 4 x relay SPST, 1 x 4 - 20mA
9 Special version, TSP-no. to be spec.
NMS5- Product designation (part 1)
Proservo NMS5
Endress+Hauser
