7.2

Settings for NMT 53x Connections

The following settings are required to display NMT 539 data on NMS5 screens.
Item
0 3 0
MATRIX OF
MORE
FUNCTION
SYSTEM
DATA
CONNECTION NMT
3 6 2
Figure. 59: Matrix Group: Service
Static Matrix
0 3 0
MATRIX OF
MORE
FUNCTION
Figure. 60: Static Matrix
Caution!
For NMT535/539/532 connections, refer to the appropriate operating manual for the device.
Procedure
1. In Static Matrix • Set access code 51.
"MORE
FUNCTION", invoke
GVH=030 "MATRIX
OF" and select
"SERVICE".
2. Invoke the Dynamic • NMS HART connection
Matrix GVH=362
"CONNECTION
NMT" screen.
3. Use the "+" and "-"
keys to display
"AVERAGE" and
press "E" to set data.
4. Press "E" to return to
"SYSTEM DATA" and
press the "-" key to
return to "MORE
FUNCTION".
5. Invoke Static Matrix
"GVH=030 MATRIX
OF". NMS5 matrix is
divided into matrix
groups.
Select
"TEMPERATURE"
from these groups.
• The Static Matrix
6. "EDITING
ENABLED" is
displayed on the
LCD.
7. The average liquid
temperature is
displayed on
Dynamic Matrix
screen GVH=440.
8. The temperature of
each contact is
displayed on
Dynamic Matrix
screens GVH=450 to
GVH=459.
7 Commissioning
Remarks
(terminal 24 & 25) must
have corresponding IS
input in order to
configure NMT IS
version.
GVH=010 "LIQUID
TEMP." screen also
displays the average
temperature.
57
