Proservo NMS5
Endress+Hauser
060 Input:
0
1
2
3
4
5
6
9
070
080
090
100
110
NMS5-
HART (NMT5xx, NRF560, pressure transmitter)
1 x spot temperature Pt100, HART (NRF560, pressure transmitter)
2 x operation contact, HART (NMT5xx, NRF560, pressure transmitter)
1 x spot temperature Pt100, 2 x operation contact, HART
(NMT5xx, NRF560, pressure transmitter)
1 x status, HART (NMT5xx, NRF560, pressure transmitter)
1 x spot temperature Pt100, 1 x status, HART (NMT5xx, NRF560, pressure transmitter)
1 x spot temperature Pt100, 1 x status, 2 x operation contact, HART
(NMT5xx, NRF560, pressure transmitter)
Special version, TSP-no. to be spec.
Measuring Range; wire:
C 0 - 28m; SUS316L, 0.15mm
L 0 - 36m; SUS316L, 0.15mm
N 0 - 47m; SUS316L, 0.15mm
H 0 - 16m; PFA>SUS316, 0.4mm
K 0 - 16m; Alloy C, 0.2mm
M 0 - 22m; Alloy C, 0.2mm
Y Special version, TSP-no. to be spec.
Cable entry:
E 4 x thread G1/2
F 4 x thread G3/4
G 4 x thread NPT1/2
H 4 x thread NPT3/4
L 4 x thread M20
M 4 x thread M25
Y Special version, TSP-no. to be spec.
Process connection:
A 10K 80A RF, flange JIS B2220
C 10K 80A FF, flange JIS B2220
U 10K 150A RF, flange JIS B2220
E 20K 80A RF, flange JIS B2220
G 3" 150Ibs RF, flange JIS B2220
J 3" 300lbs RF,flange ANSI B16.5
W 4" 300lbs RF, flange ANSI B16.5
T 6" 150lbs RF, flange ANSI B16.5
L DN80 PN10 B1, flange EN1092-1 (DIN2527 B)
N DN80 PN25 B1, flange EN1092-1 (DIN2527 B)
Q 80A 150lbs RF, flange JPI 7S-15
S 80A 300lbs RF (apply for NMS5-6), flange JPI 7S-15
Y Special version, TSP-no. to be spec.
Power supply:
3 85 - 264 VAC, 50/60 Hz
4 20 - 62 VDC, 20 - 55 VAC, 50/60 Hz
9 Special version, TSP-no. to be spec.
Displacer:
N Cylindrical 30 mm, SUS316
K Cylindrical 40 mm, SUS316
D Cylindrical 50 mm, SUS316
W Cylindrical 30 mm, PTFE
V Cylindrical 40 mm, PTFE
U Cylindrical 50 mm, PTFE
T Cylindrical 50 mm, AIloy C
B Conical 50 mm, PTFE
R Conical 70 mm, SUS316
S Conical 110 mm, SUS316
Y Special version, TSP-no. to be spec.
Product designation (part 2)
2 Identification
