Endress+Hauser Proservo NMS5 Operating Instructions Manual page 93

Proservo NMS5
Order Code List
Order Code
11 Oring
017803-0034 O-ring, cover drum housing Alu, NBR
70106019 O-ring, cover drum housing Alu, CR
70106020 O-ring, cover drum housing Alu, FKM
70106021 O-ring, cover drum housing Alu, Silicon
56004345 O-ring, cover drum housing Alu, PTFE
O-ring, cover drum housing, SS, FKM
017803-0066
017803-0035 O-ring, cover drum housing, SS, silicone
O-ring, cover drum housing, SS, NBR
70109105
70109106 O-ring, cover drum housing, D158-d3.5 CR
70109107 O-ring, cover drum housing, D158-d3.5 PFA
017803-0033 O-ring, calibration window, NBR
70106018 O-ring, calibration window, CR
017803-0041 O-ring, calibration window, silicone
017803-0036 O-ring, calibration window, FKM
56004518 O-ring, calibration window, PTFE
017803-0030 O-ring, display cover, NBR
O-ring, terminal cover, NBR
017803-0040
71070894 PTFE packin+ring, calibr. window, Zone0
21 Cover
017800-0111 Cover, display module, Aluminium
017800-0112 Cover, terminal box, Aluminum, NMS
017800-0113 Cover, drum housing, Alu, NMS531/NMS534
56004307 Cover, drum housing, SS, NMS535/536
56004308 Cover, drum housing, SS, NMS532
56004295 Calibration window, Alu, NMS531/NMS534
56004296 Calibration window, SS, NMS532/NMS535
56004297 Calibration window, SS, NMS536
Calibration window, SS, Zone 0, NMS532/535/536
71070909
31 Electronic Module, Power Module
70103940 POW-6, HV, non Ex i
70103942 POW-6, HV, Ex i
70103941 POW-6, LV, non Ex i
70103943 POW-6, LV, Ex i
32 Electronic Module, Main CPU
70103937 TCB-6, CPU module, upgrade of TCB-4
33 Electronic Module, Remote Communication
70103937 COM-1, Communication module, V1
52013661 Upgrade kit V1
71086763 Modbus module RS485, COM-5
70106270 Upgrade kit Modbus RS485
56004484 COM-6 HART, passive remote commu. module
52013651
56004485
Endress+Hauser
Parts Name Order Code
70106039 Upgrade kit HART active output
56004534 Communication module WM550, arrestor
52013662 Upgrade kit WM550
56004409 Communication module Mark Space
52013658 Upgrade kit Mark Space
56004355 Communication module ENRAF BPM, COM-3
52013649 Upgrade kit Enraf BPM
34 Electronic Module, Contact Output
017800-0007 Alarm output, 2x contact, I/O 3
70109108 Alarm output, 2x contact, I/O 3, TUV OSP
52013654 Upgrade kit I/O-3
35 Electronic Module, A/O
017800-0017 Output 4-20mA, I/O 5, TCB4
52013656 Upgrade kit I/O-5
36 Electronic Module, Ex [ia] HART Communication
56004356 Communication module EXI HART, COM-4
37 Electronic Module, I/O Spot Temperature Input
56004442 Oper. I./C.O., spot temperature
70106035 Upgrade kit oper. I./C.O., Ex d temp.
70106032 Upgrade kit oper. input/contact out
56004441 Operation input/contact out, carrier
56004491 Spot temp. with Chassis
56004490 Spot temp. input T-AMP UP grade KIT
70106027 Spot temp. Ex ia, carrier
40 Fuse
70106027 Fuse 250VAC T2A50, NMS, 10 pcs.
70106499 Fuse 20-62VDC T3A15, NMS, 10 pcs.
70106500 Fuse cover 10set, NMS
41 Connector, Cable
52013660 Wiring harness,Ter.-COM-1/RS485/BPM mod.
52013650 Wiring harness, Term.-HART passive mod.
70106037 Wiring harness, Term.-HART active mod.
52013657 Wiring harness, Terminal-Mark Space mod.
52013648 Wiring harness, Terminal-ENRAF BPM mod.
52013653 Wiring harness, Terminal-I/O-3 module
52013652 Wiring harness I/O-3-TCB
52013655 Wiring harness, Terminal-I/O-5 module.
70106036 Wiring harness, Terminal-COM-4 module
70106033 CPU, T-AMP Ex d module cable
70106034 Wiring harness,Terminal-T-AMP Ex d mod.
70105996 Wiring harness,Terminal-T-AMP Ex ia mod.
70105995 CPU, T-AMP Ex ia module cable
42 Terminal
56004508
56004509
