Type 2 - Directed DS4+ Installation Manual

Type 2

Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram (
Body ECU
(White connector
at dash fuse box)
HS CAN
19 20 21 22 23
Low:
8 10 12 13 14
Violet,
2
pin 13
(-) Trunk Release: Yellow, pin 8
Body ECU
(White connector at dash fuse box)
Driver Door Module
(White connector in drivers door)
6
16
24
(-) Lock: Gray, pin 16
(-) Unlock: Violet, pin 24
Black
Connector
Push-To-Start
(Black connector at PTS switch)
11
BTX: Black, pin 25
BRX: White or Green, pin 26
(-) Autolights: Red, pin 28
(-) Parking Lights:
Black, pin 30
27 29
15 16 17 18
5
HS CAN High:
Pink or White, pin 14
(-) PTS: Green, Pin 1
Diagnostic Connector OBDII
1 8
(connector side view)
9 16
(+) 12V: Yellow, pin 16
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
Immo. Data 2: Orange/Black: 7
Immo. Data 1: Yellow/Black: 8
(-) Parking Lights Output: Lt.Green/Black: 1
(-) Lock Output: Green/Black: 3
(-) Trunk Release Output: Red/White: 4
(-) Unlock Output: Blue/Black: 9
(-) Push-to-Start Output: Lt.Blue/Black: 10
(+) Siren Output: Brown/Red: 11
Hood Pin
Siren
(-) Hood Input: Gray: 21
Autolight Interrupt (veh. side): Blue/White: 1
Autolight Interrupt (conn. side): Blue: 3
(+) 12V Input: Red: 6 &12
(-) Ground: Lt.Green/Red: 7
(-) SLP Output: Lt. Green: 8
(-) Ground: Black: 10
(-) SLP:
Blue, pin 4
Steering Lock
(Black connector under steering column)
).
DS4+ DS4
Proper Fuse
Positioning
DS4
Slide
DS4+
to open
It is important to check that the
fuses are positioned correctly.
DS4+ TL6
