- Page 1 933.HKHT1 DS3+ / DS4+ v3.25.195.3 2013 Hyundai Sonata THHYN3-DS4+,DS3+-ONLY Compatible (Sold Separately)
-
Page 2: Table Of Contents
Contents Introduction Vehicle function compatibilities Pre-installation and application warnings Installation Wiring diagram with T-Harness (THHYN3) Wiring diagram Locating components in the vehicle Vehicle connections Module programming With Transponder Immobilizer Without Transponder Immobilizer Module programming for security-only installations Pairing remotes Connecting the module 8556T Temperature Sensor 8504D Combo Sensor RF Systems... -
Page 3: Introduction
Introduction This guide provides information on the installation of the DS3/DS3+ and DS4/DS4+ modules as a digital solution. Using these modules in a digital configuration require the module to be flashed with vehicle specific firmware. Refer to our website (www.directechs.com) and click on the DIRECTLINK text in the header for additional information. -
Page 4: Vehicle Function Compatibilities
Tach / RPM Output Driver Priority Unlock Entry Monitoring ALL Door Pins Trunk / Hatch Release Entry Monitoring Hood Pin DS4+/DS3+/VSM3 Only Entry Monitoring Trunk/Hatch Pin Control of aftermarket alarm with OEM remote Factory Alarm Trigger Monitoring Fuel level/EV battery level... -
Page 5: Pre-Installation And Application Warnings
Pre-installation and application warnings This section highlights important information for this specific firmware and will assist in pricing accordingly, as START HERE well as bringing awareness to any operational or vehicle limitations. Compatibilities and Requirements T-Harness Keys required for Keys required THHYN3 programming for operation... -
Page 6: Installation
Wiring diagram with T-Harness (THHYN3) Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( DS4+ Ignition Switch THHYN3 (Optional T-Harness) 8-Pin White Connector Parking Lights (-) Parking Lights Output: Lt. Green/Black Refer to the “Vehicle connections”... -
Page 7: Wiring Diagram
Wiring diagram Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( OBDII Diagnostic (connector side view) C-CAN High: pin 6 C-CAN Low: pin 14 HS CAN Low: Tan: 1 HS CAN High: Tan/Black: 2 B-CAN Wires HS CAN 2 Low: Orange/Brown: 3... -
Page 8: Locating Components In The Vehicle
Locating components in the vehicle 933.HKHT1 3.25.195.3 2013 Hyundai Sonata ©2022 VOXX•DEI LLC. All rights reserved. -
Page 9: Vehicle Connections
Vehicle connections The connection information listed below is specific to the 2013 Hyundai Sonata. Refer to “Pre-installation and application warnings” for a list of important notes. Data harness, 8-pin white connector (H1) Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color Connection... - Page 10 Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color Connection H2/20 Green (-) Door Input No Connection H2/21 Gray The installation of an aftermarket hood pin is only required on vehicles (-) Hood Switch Input that are not equipped with a factory hood pin or if not supported in data.
- Page 11 Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color Connection H4/9 Red/White (+) 12 Volt Input No Connection H4/10 Pink (+) Ignition Input/Output ignition switch, white 6 pin plug, pin 4 pink Mandatory RF Port harness, 2-pin white connector (H5) Module Conn./Pin Color...
-
Page 12: Module Programming
Connect the 12-pin main power harness to the module. DS3+: Wait until the LED turns on solid red then proceed to the next step. DS4+: The LED turns ON solid blue for 1 second to confirm Bluetooth communication. Wait until the LED turns ON solid red, then proceed to the next step. -
Page 13: Without Transponder Immobilizer
DS3+: Wait until the LED turns on solid red then proceed to the next step. DS4+: The LED turns ON solid blue for 1 second to confirm Bluetooth communication. Wait until the LED turns ON solid red, then proceed to the next step. -
Page 14: Module Programming For Security-Only Installations
Connect the 12-pin main power harness to the module. DS3+ DS4+ DS3+: Wait until the LED turns ON solid orange then proceed to the next step. Must connect Solid Solid Solid DS4+: The LED turns ON solid blue for 1 second to confirm Bluetooth communication. -
Page 15: Pairing Remotes
Note: Connected devices become registered within 4 to 6 seconds. 8556T Temperature Sensor The 8556T Temperature Sensor is optional, but included with your DS3+/DS4+ module. When used, the Temperature Sensor must be plugged into the 2-pin black connector of your module. -
Page 16: When Used In Conjunction With Smartstart
Loops Pigtails DO NOT connect the Directed SmartStart ® 2-pin power harness when using the DS3+/DS4+. Power and ground will be provided by the D2D connector on the module. Refer to the Directed SmartStart ® documentation for further details. D2D port configuration Caution! Do not connect the Control Center (antenna) or any digital sensors (8504D) to the white D2D1 port. -
Page 17: Manual Transmission
Manual Transmission IMPORTANT! Directed does not approve nor support installations of manual transmission and remote starts on any electronic vehicles (EV), OEM Remote Start Activation firmware, vehicles with convertibles and/or removable tops, including but not limited to Jeep Wrangler, Honda S2000, Mazda Miata, and other such vehicles. -
Page 18: Led Diagnostics And Troubleshooting
LED diagnostics and troubleshooting This section provides LED diagnostics and troubleshooting information to guide you through the various stages of your installation. Module Programming Description Troubleshooting Make sure the D2D harness is connected and that 12 Volt is present between the red and black wires. If Module has no power. - Page 19 External Module Synchronization Description Troubleshooting OBDII feature not supported. The diagnostic data bus was not detected, therefore the SmartStart features will be limited. (Flashes red, red, then orange) x 10 Active Ground When Running (Status) Description Troubleshooting Ground When Running (Status) command The module has initialized the remote start sequence.
-
Page 20: Soft Reset
If required for your installation, connect all the harnesses to the module, EXCEPT the 12-pin main 12-pin harness power harness. Press and hold the programming button, then connect the 12-pin harness to the module. DS3+: Wait 3 seconds until the LED turns ON solid orange then release the programming button. & &... -
Page 21: Tach Learning Procedure (Not Needed With Virtual Tach)
Tach learning procedure (not needed with Virtual Tach) Data Tach: The procedure is not required as the tach comes preprogrammed. However, it is strongly recommended to learn the exact value of the vehicle for the most consistent and reliable starting and functionality. Hardwired Tach: The procedure is required. -
Page 22: Limited Lifetime Consumer Warranty
Limited Lifetime Consumer Warranty VOXX DEI LLC (the Company) warrants to the original purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or work- manship within the Lifetime from the date of original purchase in the original vehicle, such defect(s) will be repaired or replaced with new or reconditioned product, (at the Company’s option) without charge for parts or repair labor. -
Page 23: Quick Reference Guide
& 2. Aftermarket remote. The parking lights will flash once to indicate the vehicle is Parking lights flash x1 Press Remote 3. Directed SmartStart application via your smartphone. now in Pit Stop Mode. ® Start button* Exit the vehicle with the factory remote in hand (it is safe If applicable, you can also start the engine remotely by pressing the Lock button 3 times to leave the engine running). - Page 24 SmartSchedule, vehicle status, roadside assistance, parked car finder and more. The application enables a “Cloud-Connected Car” like never before, providing 2-way interaction with your vehicle. Connectivity is managed through the Directed Cloud Services (DCS) network linking car, app, end user, and the Internet.
