Directed DS4+ Installation Manual page 22

Wire Information
Function
Toyota Camry Hybrid 2016-2017
SLP
PTS
12V
BTX
BRX
Parking Lights
Autolight
HS CAN High
HS CAN Low
Toyota Corolla (Smart Key) 2017
SLP
PTS
12V
BTX
BRX
Parking Lights
Autolight
HS CAN High
HS CAN Low
Toyota RAV4 (Smart Key) 2016-2017
SLP
PTS
12V
BTX
BRX
Parking Lights
Autolights
HS CAN High
HS CAN Low
22
Color Pin Polarity
Green or Pink 4 (-)
Violet 1 (-)
Red 16 (+)
Green 25 Data
Red 26 Data
Black 30 (-)
Green 28 cut
Pink 14 Data
White 13 Data
Green 4 (-)
Black 1 (-)
Green 16 (+)
Empty, insert 25 Data
pin
Empty, insert 26 Data
pin
White 30 (-)
Violet 28 cut
Black 14 Data
White 13 Data
Lt. Green 4 (-)
Dk. Green 1 (-)
Blue 16 (+)
Blue 25 Data
Red 26 Data
White 30 (-)
Green 28 Cut
Green 14 Data
White 13 Data
Connector Information
Location
Steering lock under steering column.
PTS (Push-to-Start) switch.
OBDII.
Body ECU on bottom dash fuse box.
Body ECU on bottom dash fuse box.
Body ECU on bottom dash fuse box.
Body ECU on bottom dash fuse box.
Body ECU on bottom dash fuse box.
Body ECU on bottom dash fuse box.
Steering lock under steering column.
PTS (Push-to-Start) switch.
OBDII.
Body ECU on bottom dash fuse box.
Body ECU on bottom dash fuse box.
Body ECU on bottom dash fuse box.
Body ECU on bottom dash fuse box.
Body ECU on bottom dash fuse box.
Body ECU on bottom dash fuse box.
Steering lock under steering column.
PTS (Push-to-Start) switch.
OBDII.
Body ECU on bottom dash fuse box.
Body ECU on bottom dash fuse box.
Body ECU on bottom dash fuse box.
Body ECU on bottom dash fuse box.
Body ECU on bottom dash fuse box.
Body ECU on bottom dash fuse box.
Color Pins Ref.
Black or Blue 7 A
Black 10 B
Black 16 C
White 30 D
White 30 D
White 30 D
White 30 D
White 30 D
White 30 D
Black 7 A
Black 10 B
Black 16 C
White 30 D
White 30 D
White 30 D
White 30 D
White 30 D
White 30 D
Black or Blue 7 A
Black 10 B
Black 16 C
White 30 D
White 30 D
White 30 D
White 30 D
White 30 D
White 30 D
DS4+ TL6
