Installation (Wiring Diagrams, Fuse Selection & Vehicle Wiring Reference Charts); Type 1 - Directed DS4+ Installation Manual

Installation (wiring diagrams, fuse selection & vehicle wiring reference charts)

Type 1

Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram (
BTX: Blue, pin 25
Body ECU
(White connector at dash fuse box)
19 20 21 22 23 27
8 10 12 13 14 15 16 17
2
(-) Unlock: Gray, pin 24
(-) Lock: Red, pin 11
(-) Trunk Release: Red, pin 5
(White connector at dash fuse box)
Certification ECU
(White connector behind glove box)
9
BRX: Red, pin 26
(-) Autolights: Green, pin 28
(-) Parking Lights:
White, pin 30
29
18
5
Body ECU
(-) PTS: Violet, pin 30
HS CAN High: Blue, pin 6
Diagnostic Connector OBDII
1 8
(connector side view)
9 16
HS CAN Low:
(+) 12V: Blue, pin 16
White, pin 14
HS CAN High: Tan/Black: 2
Immo. Data 2: Orange/Black: 7
Immo. Data 1: Yellow/Black: 8
(-) Parking Lights Output: Lt.Green/Black: 1
(-) Lock Output: Green/Black: 3
(-) Trunk Release Output: Red/White: 4
(-) Unlock Output: Blue/Black: 9
(-) Push-to-Start Output: Lt.Blue/Black: 10
(+) Siren Output: Brown/Red: 11
Hood Pin
Siren
(-) Hood Input: Gray: 21
Autolight Interrupt (veh.side): Blue/White: 1
Autolight Interrupt (conn.side): Blue: 3
(+) 12V Input: Red: 6 &12
(-) Ground: Lt.Green/Red: 7
(-) SLP Output: Lt. Green: 8
(-) SLP:
Pink, pin 4
Steering Lock
(Black connector under steering column)
HS CAN Low: Tan: 1
DS4+
Proper Fuse
Positioning
(-) Ground: Black: 10
Slide
to open
It is important to check that the
fuses are positioned correctly.
© 2017-10-03 Directed. All rights reserved.
).
DS4
DS4
DS4+
DS4+ TL6
