Installation (Wiring Diagrams, Fuse Selection & Vehicle Wiring Reference Charts); Type 1 - Directed DS4+ Installation Manual

Installation (wiring diagrams, fuse selection & vehicle wiring reference charts)

Type 1

Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram (
Headlight Switch
(White conn. headlight switch)
10 9 8 7 6 5 4 3 2 1
20191817161514131211
(-) Autolights:
Orange, pin 19
Driver Door Window Switch
(White conn. in driver door)
(-) Lock: Lt. Green, pin 4
10 4 1
20 13 11
(-) Unlock: Pink, pin 13
CUT
(+) 12V: White, pin 1
1
Fuse Box
(White conn. under driver dash)
8
(-) Parking Lights:
Blue, pin 18
Power ECU
(White conn. behind glove box)
6 1
17 7
26 18
21
If the module programs, but the vehicle starts
and stops following a remote start command,
reverse the IMI wires. The Yellow/Black and
Lt.Green wires need to be on the ECM side.
(+) Starter1 :
Lt. Blue, pin 17
17 15
40 35
Power ECU.
(White conn. behind glove box)
Junction connector
(White conn. drivers kick panel)
22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7
6 5 4 3 2 1
3837363534333231 3029 28 27 26 25 24 23
444342414039
60595857565554535251 50 49 48 47 46 45
IMI: Lt. Green, pin 49
IMO: Pink, pin 48
(-) Trunk Release:
Blue, pin 21
Hood Pin
Siren
CUT
(+) Starter 2: Blue, pin 15
(+) Accessory: Green, pin 11
1
11 10 9
34 32 26 18
Ignition 2: Lt. Blue, pin 34
Ignition 1: Yellow, pin 35
CAN High: Blue, pin 6
1 8
9 16
CAN Low: Lt.Green, pin 14
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
IMO Data: Orange/Black: 7
IMI Data (conn. side): Yellow/Black: 8
(-) Parking Light Output: Lt.Green/Black: 1
(-) Lock Output: Dark Green/Black: 3
(-) Trunk Release Output: Red/White: 4
(-) Unlock Output: Dark Blue/Black: 9
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
Autolights Interrupt (conn. side) Blue/White: 1
Autolights Interrupt (veh. side) Blue: 3
(+) Starter 2 Output: White: 5&11
(+) 12V Input: Red: 6&12
IMI Interrupt (conn. side):Lt. Green: 8
IMI Interrupt (vehicle side):Lt. Green/White: 9
(-) Ground: Black: 10
(+)12V Input: Red/Black: 2
(+) Ignition 2 Output: Pink/White: 4
(+)12V Input: Red: 5
Starter Input (Key side) : Green: 6
(+) Starter Output : Violet: 7
(+) Accessory Output: Orange: 8
(+) 12V Input: Red/White: 9
(+) Ignition 1 Output: Pink: 10
).
Diagnostic Connector OBDII
(connector side view)
DS4+ DS4
Proper Fuse
Positioning
DS4
Slide
DS4+
to open
It is important to check that the
fuses are positioned correctly.
DS4+ TL4
