Using the internal web pages

7.10. Device Management

The Device Management page has six tabs: General, SNMP, MX, Auto Discovery,
Firmware, and Reboot.
7.10.1.
Identification
This section offers administrative module information.
Device name
This section contains label settings, which can be edited and saved.
Label 1 / Label 2
Figure 7.59 Device Management page, General tab

General

Values entered for the Label 1 and Label 2 variables are stored in the
Management Information Base (MIB) of the module. The labels jointly
constitute the device label, a user friendly name for the physical device,
which will serve to identify and address the module on the network
when working with the MX network service and MX applications. The
current value for Label 1 is displayed in the upper pane of the web
pages.
Figure 7.60 Label 1 value (encircled in red) in upper pane of web page
- 71 -
