Using the internal web pages
RTSP Transmitter
DSCP field
Default multicast IP
address
Default multicast
port
SAP settings
The C-54 E includes a SAP announcer. The Session Announcement Protocol is used to
advertise that a media stream generated by the C-54 E is available at a specific multicast
address and port. For more information about SAP, see the note below.
Enable SAP
Stream name
Stream dest. IP
Stream dest. port
Stream DSCP field
Multicast TTL
Announcement
interval
Figure 7.20 RTSP Transmitter settings
[0...63]. For details, see Transmitter # settings.
Destination IP address for multicast sessions.
Port number for multicast sessions.
Figure 7.21 SAP settings
When selected, session announcements are sent at the frequency
determined by the Announcement interval parameter.
Enter a descriptive name to identify the media stream.
Specify the multicast IP address the media stream is sent to. This
address must be within the range defined by the Multicast IP range
parameter.
The destination port number. Default: 1024.
[0...63]. For more information about DSCP fields, see Transmitter #
settings.
[0...255]. Specify the number of routers (hops) that multicast SAP
packets are permitted to pass through before expiring on the
network.
Determines the frequency of announcements.
