Using the internal web pages
Zoom out
Focus far
Focus near
Iris open
To enter and save a preset camera position
1. Enter the preset number by clicking the corresponding number button.
2. Adjust the camera's position for the desired view.
3. When satisfied with the position, click
(The SET button is not available to users with Viewer rights.)
To call a preset camera position
1. Enter the preset number by clicking the corresponding number button.
2. Click
To erase a preset camera position
1. Call the preset (see above).
2. Press
3. If desired, override the preset with a new preset position.
Zoom in
Iris close
.
GO
.
Clear
.
SET
- 31 -
Click arrows to pan and
tilt the camera (at fixed
speed)
Click ball to pan and tilt
the camera (point of
clicking determines
pan/tilt speed)
Figure 7.8b
PTZ Control panel
