Using the internal web pages
To remove a font
1. Log on to Font management as root or admin.
2. In the Font management section (see figure 7.33), select the font.
3. Click the
Graphics tab
The Graphics tab enables you to upload graphics (see Graphic management), and scale and
position a selected graphic on your screen.
Predefined positions
Transparency
X and Y Position
X and Y Scaling
factor
Show Preview>>
Encoder
<< Hide Preview
button.
Del
Figure 7.35 Graphics tab with 3 OSD bars and a graphic (top left) in the preview
Presets for graphic positions.
Drag the sliding button or enter a percentage.
Enable you to freely position the graphic.
Enable you to freely configure the dimensions of the graphic.
Click to see live images and the effect of your settings.
The encoder handling the images seen in the preview.
Hiding the preview may improve web page responsiveness.
Figure 7.34 Selecting a font
- 55 -
