Using the internal web pages
Advanced OSD bar # settings
The first time you access Advanced OSD settings after opening your web browser, you are
asked to authenticate. Next, a security alert will display. Using the Font management feature
requires Java Runtime Environment 1.6 or higher. The Optelecom-NKF application does not
give rise to any security risks. You can run it safely.
Font name
Render mode
X- and Y-position
anchor point
Rotation angle
Font management
For OSD texts, you can use the C-54 E's default fonts or fonts you upload to the module.
To upload a font
1. Log on to Font management as root or admin.
2. In the Font management section, click
The Open dialog box displays.
3. Browse to the folder containing the font to be uploaded.
4. Select the correct file (.ttf extension), and then click
The file appears in the File textbox.
5. To start the upload, click
The new font is added to the Font list and to the Font name drop-down list in the
Advanced OSD Bar # Settings section.
Figure 7.32 Advanced OSD bar settings
Offers a selection from default and uploaded fonts (see Font
management).
Outline or Border (see figure 7.32).
Enable you to shift the OSD bar relative to the anchor point.
Background size automatically adjusts to text dimensions when a bar
is rotated.
Figure 7.33 Font management section
.
Add
- 54 -
.
Browse
(figure 7.34).
Open
