Using the internal web pages
To remove a driver
1. In the PTZ driver management section (see figure 7.54), log in as admin or root.
2. Select the driver.
3. Click the
Data settings
Bit rate
Word length
Stop bits
Parity mode
Any changes you make in the Data settings section will be copied to the RS-422/485 page.
button.
Del
Figure 7.57 PTZ page, data settings
1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 bit/s
5, 6, 7, 8
1, 2
None, Odd, Even, Mark, Space. This setting should be the same as in the
connected device (i.e. the PTZ camera).
Figure 7.58 Changing settings in the Data settings section
will affect the Data RS-422/485 page
