Using the internal web pages

7.7.2. Encoder 1/2

Encoder 1/2 settings
Enable
Encoding mode
Figure 7.13 Video Input1 page, Encoder 1 tab
All encoders can be enabled and configured separately.
The method used to compress the analog video input signal.
MPEG-2, MPEG-4 or MJPEG.
If VMD configuration (see section 7.7.5) is to be available,
Encoder 2 must be set to MPEG-4 mode.
The C-54 E can stream MJPEG over UDP and HTTP.
To enable and configure UDP/MJPEG streaming, select MJPEG
encoding mode on this tab and configure settings.
To transport MJPEG over HTTP and/or to use the Live View previews
in the web pages, go to the Live View Encoder tab, enable the Live
View Encoder and configure its settings.
- 38 -
